MAINS CONNECTION

Your unit has been supplied with a mains lead and a fitted plug. This is identified by the fuse holder in the base of the plug.

Please read the following safety instructions before use.

1. If the fitted plug is cut off from the mains lead then the plug must be disposed of safely. NEVER under any

circumstances insert such a plug into a 13 amp socket.

2. NEVER under any circumstances use the appliance or mains lead without the fuse cover fitted. This is the little cover

fixed into the base of plug to hold the fuse in place.

3. If you lose the fuse cover then please contact any electrical dealer for a replacement or ring our helpline.

4. A replacement fuse must be rated at 13 amp. These must be manufactured and approved to BS1362.

5. IF IN ANY DOUBT PLEASE CONSULT AN ELECTRICIAN.

If you need to fit a plug to the mains lead, this should be fitted in accordance with the wiring instructions below, and will

need to be used with a 13 amp fuse. If in doubt consult an electrician.

WARNING - THlS APPLIANCE MUST BE EARTHED. If you are using an extension lead it must be rated at a minimum

of 10 amps and fully unwound. Do not operate with a lead rated at less than 10 amps as this will cause premature failure

of the element which is not covered by the guarantee.

As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying

the terminals in your plug, proceed as follows:

The wire which is coloured green and yellow must be connected to the terminal in the plug which

is marked with the letter E or by the earth symbol, or coloured green or green and yellow.

The wire which is coloured blue must be connected to the terminal which is marked with the letter

N or coloured black.

The wire which is coloured brown must be connected to the terminal which is marked with the

letter L

or coloured red.

4

B40 02/08

GUARANTEE

This product is guaranteed for a period of 24 months against faulty materials and workmanship. Whilst every possible

care is taken by the manufacturer to ensure that our products leave the factory in good working order, the manufacturer

cannot under any circumstances accept liability for problems or damage caused by their subsequent use. It is the

responsibility of the user to ensure that surfaces to be treated, cleaned or stripped are suitable for steam. This guarantee

does not affect your statutory rights. This guarantee excludes the use for hire purposes.

EC Declaration of Conformity

We declare that the units:SS75, SS76, SS77, SS125 conform to: 2006/95/EC, BSEN60335-1, BSEN60335-2-54 &

89/336/EEC, EN55014-1, EN55014-2, EN61000-3-2, EN61000-3-3, EMF EN50366.

T

im Hopper-Technical Director

INFORMATION ON THE DISPOSAL OF WASTE ELECTRICAL EQUIPMENT KNOWN AS WEEE

Your attention is brought to new directives applicable to the disposal of this electrical equipment, where in

accordance with the legislation this product must not be disposed of in your normal household waste. Instead

it is your responsibility to dispose of this type of waste by handing it over to special designated collection points

for recovery and recycling. This product is marked with a ‘Wheelie bin’ symbol with a cross on it to remind you

of this action. The objective of this directive is to help conserve resources and ensure that it is recycled in a

manner that protects human health and the environment. For more information about where you can drop off

your waste please contact your local authority, take back facilities are free of charge.

MIN SIZE 5mm WIDE X 7mm HIGH

Earlex Ltd., Opus Park, Moorfield Road, Guildford, Surrey

. GU1 1SZ.

Tel: +44 (0) 1483 454666. Fax: +44 (0) 1483 454548.

email: [email protected] website: www.earlex.co.uk

© Earlex Ltd. 2008

TROUBLE SHOOTING

l

Unit Fails to Boil

The unit has probably not been left for long enough to cool - refer to section on safety cut-out. Check the fuse in the

p

lug is sound and is rated at 13 amps.

If using an extension lead check that it is rated at a minimum of 10 amps and fully unwound.

l

Unit Leaks Steam from Pressure Relief Valve

T

he pressure relief valve is a special low pressure valve and cannot be replaced by any other valve. If steam is leaking

from the valve, the most likely cause is a blockage in the hose. Allow the unit to cool then remove the hose and check

for any blockage. Always check the inlet in the tool you are using.

UNDER NO CIRCUMSTANCES FORCE THE VALVE SHUT. THIS IS OPERATING FOR YOUR PROTECTION.

DESCALING

To maintain peak performance of the unit, particularly in areas of hard water, it may be necessary to descale the

element in the unit. Proprietary kettle descaling products can be used in your unit - always follow the manufacturer’s

i

nstructions.

IF YOU REQUIRE FURTHER ASSISTANCE PLEASE CONTACT OUR HELPLINE ON:

Tel: 01483 454666 Fax: 01483 454548

Opening Hours: Monday - Friday 08.30-17.00 (Except Bank Holidays)

Patents: GB2294515, GB2300698, GB2 422 731, GB2,253,685, GB 1059125, DE19539236.1, DE29522026,

DE690 04 269 T2, FR 06/03977, US5,762,108, PCT/GB06/001222, DE 20 2006 007 103.2

Design Registration Nos: GB 2046683, GB 3004739, GB 2046682, DE 40205274.9, FR 02 4020, US D496,504 S.

B40 02-08.qxd 25/7/08 10:33 am Page 4
