Bruksanvisning Earlex SS100 Tapetborttagare

Bruksanvisning

2

CAUTION !

Check the state of your plaster before starting work.

Steam can loosen weak, porous or poorly bonded plaster - which also loosens readily if cracked, holed or if the steam

plate is held in one position for too long after the paper is soaked.

Weak plaster can normally be detected by tapping a few areas of wall. A hollow sound indicates that you should

proceed only with extreme care - stopping immediately if you hear a cracking sound or plaster starts to break loose.

The steam stripper is safe for drywall/plaster board surfaces but whatever the material, it is always wise to check a

small area before starting work properly.

PREPARATION

To achieve fastest paper removal always gently score the areas to be stripped.

With heavily embossed, vinyl coated or painted papers this is essential. Either use a proprietory

perforator tool or alternatively score the paper with the edge of a wall scraper in a criss-cross

pattern with 150mm (6 inch) spacing.

As with all decorating work be sure to protect carpets and furniture with covers.

FITTING CORNER BUMPERS AND CASTORS

A pack of 4 plastic corner pieces and 4 castors is enclosed to protect the unit. To fit the corner pieces

simply push these over the aluminium edges at each corner and press home. To fit the castors turn the

boiler upside down and push the castors in hard until they stop. Once installed these remain in place

permanently.

OPERATION

STEAM IS HOT! The unit is designed for safe, fast removal of wallpaper but please be aware that steam is produced at

100

o

C - so be careful, wear protective clothing and protect your hands with heat resistant gloves or mitts.

FILLING:

Remove filler cap and fill unit to Max. level line or indicator with clean - preferably hot - water. Replace filler cap.

The capacity of 4.5 litres (8 pints) provides approx.70 mins. steaming time before the safety cut-out operates.

For a shorter steaming time use less water. Do not overfill the unit or hot water will be forced up the steam hose.

Screw hose onto threaded outlets of boiler and steam plate, hand tight is sufficient. Do not over tighten but do check

for hand tight fit from time to time during use.

Connect mains lead from unit to power socket and switch on. lt can take up to 15 mins (approx.) before steam is

produced - depending on fill water quantity and temperature.

Do not leave unattended and keep children & pets out of the room.

Just before full steam production a small amount of bubbling and water will occur at the steam plate.

Beware of hot water discharge prior to steam emission.

· Keep equipment away from children and pets.

· Ensure boiler is placed on a flat level surface, and

should the boiler become tilted in use - level again

immediately.

Failure to do so can result in severe overheating,

complete element failure and void of your guarantee.

· Block boiler unit securely if using on stairs.

· The boiler becomes hot in use. Move only by using

the carrying handle.

· Steam is produced at 100

o

C. Be careful, wear

protective clothing and protect your hands with heat

resistant gloves or mitts.

Never point hose or steam plate at anyone.

· Always keep steam plate tilted away from face and

body, beware of hot drips and regularly empty

collected condensation from plate - especially when

stripping ceilings and high areas.

Never remove filler cap or detach hose whilst unit is

operating.

Never block the safety valve.

Switch off and wait for 2 minutes before removing

filler cap to refill boiler.

Do not overfill.

Allow to cool completely before emptying boiler.

· Do not stand on boiler or hose.

· Do not drag or try to move boiler by pulling the

mains lead.

· Do not allow water or steam to enter light switches

or power points.

· Do not leave unattended.

Use only standard tap water. Never add detergents

or chemicals.

Extreme care must be taken if the unit is used in

bathrooms. Always be aware of danger of

electrocution from stored water in baths and sinks.

Never change tools when the unit is operating.

Always store upright.

Do not overfill the reservoir.

It is recommended that a RCD (residual current

device) rated at 30mA is fitted into the mains supply

socket for added protection against electric shock.

SAFETY RULES
