1
ENGLISH
ENGLISH
Accessories······················································································1
Using the HD Radio
TM
receiver·······················································1
About the remote control unit ······················································1
Part names and functions······························································1
Display····························································································1
Rear panel ······················································································1
Remote control unit ·······································································2
Contents
This manual includes explanations of functions that are added after
upgrading the receiver.
For instructions on operating the receiver, also refer to the operating
instructions included with the receiver.
Specifications·················································································4
Accessories
Check that the following parts are attached in addition to the main
unit:
q Operating instructions ..............................................................1
w ZONE remote control unit (RC-1066) .......................................1
e R03/AAA batteries....................................................................2
r AM loop antenna (for HD Radio broadcasting).........................1
t FM indoor antenna (for HD Radio broadcasting)......................1
Getting Started
Using the HD Radio
TM
receiver
HD Radio technology provides higher quality sound than conventional
broadcasts and allows reception of data services.
• FM sounds as sensational as CDs
• AM sounds as rich as analog FM stereo
•A variety of “data services”, including text-based information-
song title, artist name, album name, genre, etc.
Furthermore, in addition to conventional broadcasts, with HD Radio
broadcasting it is possible to choose from up to 8 multicast programs.
For detailed information on HD Radio technology, please go to
“www.ibiquity.com”.
About the remote control unit
The procedure for inserting the batteries and the operating range of the
ZONE remote control unit (RC-1066) are the same as for the ZONE
remote control (RC-1056) unit included with the set. For details, see
page 2 of the included operating instructions.
Part names and functions
Display
DIGITAL indicator
This lights when an HD broadcast has been received.
Rear panel
ANTENNA terminals
Listening the HD Radio
TM
broadcasting ········································2
HD Radio auto preset memory ······················································2
HD Radio auto tuning·····································································3
HD Radio manual tuning ································································3
Selecting HD Radio audio programs ··············································3
HD Radio preset memory ······························································3
Recalling HD Radio preset stations················································3
Switching HD information display··················································3
Connecting the antenna terminals ···············································2
Getting Started
Connections
Operation
HD Radio™ technology manufactured under license from iBiquity
Digital Corporation. “iBiquity Digital” and the “HD Radio” and “HD”
symbols are registered trademarks of iBiquity Digital Corporation.
U.S. and Foreign Patents.
(Large size) (Dipole)
