Bruksanvisning Cordo FB6 Cykeldator

Bruksanvisning

Technical data

Wheel circumference: 10-3999 mm

Default wheel circumference setting: 2205 mm

Battery type: CR2032

Battery life (1h/trip/day): approx. 2 years

Operating temperature: 0-40º C

Energy saving modus: after 5 min. of inactivity

Wake up: via push button or signal input

Warning

Remove the computer from the contact plate when not in use to increase the

lifespan of the battery. Storage of an unused computer in its holder for a period

longer than 14 days will result in a malfunction of the wake up feature.

Use the push button at the rear to activate the computer.

Do not expose the bicycle computer to direct sunlight when not in use.

Do not open the computer, unless changing batteries. To avoid possible

accidents do not occupy yourself excessively with the computer when riding.

Check the position of the sensor and magnet at regular intervals.

User’s instruction

Cordo FB6 bicycle computer

ENG

Display indicators

Flashing = bicycle in motion

Energy saving mode

Activated after 5 minutes inactivity

Tyre circumference

• Enter the tyre circumference in mm (see table below)

• Switch to the ATM mode (ATM = total riding time)

• Press MODE and RESET at the same time for

2 seconds to change the tyre circumference.

• Press RESET to alter digits.

• Press MODE to change to the next digit.

• After the 4th digit, press RESET to choose between km/h and mph.

• Press SET to save the settings.

1 Sensor activity

2 SCAN symbol

3 MODE symbol

4 Clock symbol

5 RESET button

Instructions for use

6 Speed

7 km/h or mph

8 Sub display

9 SET button (rear)

10 MODE button

1 Clock with 24 hour display

Press the MODE button and select Clock.

Press SET at the rear for 2 seconds. Select digits with

MODE. Set digits with RESET and press SET to save

settings.

2 DST / Distance

Total distance up to 99.999 km

3 ATM

Total riding time up to 9:59:59 h

4 ODO

Total distance: up to 99.999 km

Press MODE and select ODO modus.

Press SET at the rear for 2 seconds.

Press MODE to select the next digit.

Press RESET to alter digits.

Press SET to save the settings

5 RESET

Press MODE and select DST or ATM.

Press RESET for 2 seconds to reset DST or ATM.

6 SCAN

Press MODE for 2 seconds to activate SCAN.

SCAN only functions when the bicycle is moving.

Press SCAN again for 2 seconds to stop SCAN.

Assembly

1. Bicycle computer

2. Contact plate

with sensor

3. 3x rubber washers

(2x 32mm,

1x 42mm)

4. Base plate

5. Magnet

6. Battery (CR2032)

The bicycle computer is secured by turning it in a clockwise direction.

To remove the bicycle computer, turn it in an anticlockwise direction.

Contents of packaging Securing the bicycle computer

Assembly contact plate Fitting the sensor

Insert battery

Can be fitted to the handlebar or stem. To change the position,

loosen the base plate, turn it 90º and secure the contact plate again.

Use the rubber washers to fix the contact plate to the handlebar or

handlebar post.

1.

The sensor should be secured on the same side

as the bicycle computer using a rubber washer.

Use a coin to open and close the battery compartment.

Insert the battery with the + pole at the top.

Controlling the display after renewing the batteries will ensure

that they have been

properly placed.

2.

Screw the magnet onto a spoke.

3.

Align the center of the magnet to

the mark on the sensor.

The distance between the magnet and the

sensor should not exceed 5 mm.

www.cordo.com

1: attach 2: cllick and ‘turn 3: detach

contacts

centre of

the magnet

sensor

marking

click
