Bruksanvisning

English

GREAT BRITAIN • customer service

tel: 0845 300 9799 e-mail: [email protected] internet: www.clasohlson.com/uk

1 2 3 4

Ver. 20140401

Wireless Bluetooth

Keyboard

Art.no 18-8400 Model OY681

38-6371 OY681

Please read theentire instruction manual before using thepro-

duct and then save it for future reference. We reserve theright

for any errors in text or images and any necessary changes

made to technicaldata. In theevent of technical problems or

other queries, please contact our Customer Services.

Safety

• Do not subject thekeyboard to knocks andblows.

• Do not place thekeyboard where there is arisk that it may

fall into water or other liquids.

• Do not plug in or unplug theUSB cable with wethands.

• Do not place thekeyboard close to astrong heat source or

expose it to direct sunlight for prolonged periods.

• Never attempt to tamper with, repair or modify thekeyboard

in anyway. Thebuilt-in battery cannot be replaced.

• Use only theincluded USB cable for charging thekeyboard.

Buttons and functions

Installation

Charging

1. Connect theUSB cable to acomputer or other USB

charging device. Thered LED indicator (3) will come on to

show that charging is in progress.

Note: Thekeyboard should be charged for at least 4 hours

before it is used for thefirst time or after a long period of

non-use.

2. When theLED indicator goes out, thekeyboard is fully charged.

Establishing aBluetooth connection with

atablet/mobile phone/computer,etc.

Note:

• Thekeyboard can only be paired with one device at atime.

• If, for example, you have thekeyboard paired with your

iPad and then decide to pair it with your mobile phone

instead, you can’t just reactivate theprevious connection to

youriPad. Youwill have to delete thekeyboard (Bluetooth

keyboard) from thelist of Bluetooth devices connected to

your iPad and then carry out anew Bluetooth device search

to re-establish theconnection.

Care and maintenance

Wipe thekeyboard clean with adry cloth as and when required.

Troubleshootingguide

Thekeyboard

won’t turnon.

Thebattery might beflat. Charge thekeyboard

battery by connecting theincluded charge

cable to acomputer or other USB charger.

Thekeyboard

doesn’twork.

• Make sure that aBluetooth connection

has been properly established. Referto

theEstablishing aBluetooth connection...

sectionabove.

• Make sure that no other wireless devices

are interfering with thewireless keyboard

connection.

• If thedevice that you are attempting

to connect thekeyboard to is already

connected to another Bluetooth device,

this may impair or prevent thekeyboard

from pairing with thedevice. Disconnect

theother (disrupting) wireless device.

Disposal

This product should be disposed of in accordance with local

regulations. Ifyou are unsure how to proceed, contact your

local council.

Specifications

Bluetooth 3.0

Range approx. 10m

Charging current 5V, 100mA

Built-in battery 320mAh, Li-pol

Operating temperature 0–35 ºC

1. USB port for theincluded chargecable

2. [ OFF/ON ] OFF/ON switch

3. LED charge indicator

4. LED Bluetooth indicator

1. Set the [ OFF/ON ] switch

(2) on thekeyboard to

theON position.

6. Apassword will now appear on

your device. Writethepassword

on thekeyboard and press

[ ENTER ]. Thetwo devices will

now connect (pair) with eachother.

3. Theblue LED Bluetooth indicator (4)

will flash to show that thekeyboard is

detectable for other devices.

2. Hold in [ F1 ] (thebutton

with theBluetooth symbol)

for 3 seconds.

7. Thedevices are now

paired.

4. Activate Bluetooth on thedevice to be connected to

thekeyboard. Referto theinstruction manual of your device

for further clarification if you are unsure.

5. Thekeyboard will now appear on your device as “Bluetooth

keyboard”, selectit.
