Bruksanvisning Clas Ohlson MF-H09 Ficklampa

Bruksanvisning

English

1 2

3 4

6

7

5

Ver. 20230403

Head Torch 10 W/500 lm

Art.no 31-2579  Model MF-H09

Please read theentire instruction manual before using theproduct and

then save it for future reference. Wereserve theright for any errors in

text or images and any necessary changes made to technicaldata.

Ifyou have any questions concerning technical problems please

contact our Customer Services.

Safety

• Do not point thelight beam into anyone’seyes.

• Do not let children play with theproduct.

• Never charge thetorch in flammable environments or on flam-

mable surfaces.

• Only use theincluded rechargeable battery.

• Never immerse thehead torch in water or other liquid.

• Never expose thebattery to high temperatures or naked flames.

• Avoid contact with leaking batteries.

Product description

Inserting thebattery

Care and maintenance

• Clean thetorch using asoft, dampcloth.

• Never use cleaning agents or other chemicals.

Responsible disposal

1. Powerbutton, LED-indicator

2. LEDBulb

3. Battery type 18650 (1×)

4. Batterycover

5. USB-C cable

6. Headband

7. Belt clip

Charging the battery

1. Connect the charging cable to the

USB-C port and

any USB charger.

2. The battery indicator shows the charge

status:

Red 0−25%

Orange 25−75%

Green 75−100%

3. Charging normally takes about 5 hours.

Operating instructions

Pressthepower switch (1) to turn thehead torchon. Select thedesi-

red mode by pressing thepower switch therequired number oftimes:

Setting thelightmode

Press thepower switch repeatedly to advance through thesequence

of power settings: Verylow – low – medium – high – turbo – verylow

and soon.

Switching thetorchoff

Holding thepower switch pressed in for more than 1 second will

switch thetorchoff.

This symbol indicates that this product should not be

disposed of with general householdwaste. Thisapplies

throughout theentire EU. Inorder to prevent any harm to

theenvironment or health hazards caused by incorrect

waste disposal, theproduct must be handed in for

recycling so that thematerial can be disposed of in

aresponsible manner. Whenrecycling your product, take

it to your local collection facility or contact theplace of

purchase. Theywill ensure that theproduct is disposed

of in anenvironmentally sound manner.

Specifications

Cherger Cable USB-A to USB-C

Battery Li-ion-battery 3500 mAh (type 18650) (1×)

Operatingtime Up to 3 hours 30 minutes (350 lm)

Colour temperature 6500K

Beamangle 45°

Colour rendition Ra70

Power 10W

Light output Verylow (1lm), low (70lm), medium (200lm),

high (350lm), turbo (500lm)

Operating temperature −20 to +50ºC

IP-rating IP44

Weight 41/135g (without/with battery and headband)

Size 98.5 mm long, 25 mm diameter

Unscrew thebattery

cover (4) and insert

theincluded rechargeable

type 18650 battery

(3) in accordance with

thepolarity markings.
