English
6
3
2
1
4
5
Ver. 20230831
Wireless Doorbell
Art.no 36-8974 Model 98233EU
Please read theentire instruction manual before use and
then save it for future reference. Wereserve theright for any
errors in text or images and any necessary changes made
to technicaldata. Intheevent of technical problems or other
queries, please contact our Customer Services.
Safety
• Never subject theproduct to high temperatures, damp or
dusty environments, heavy vibrations or impacts.
• Theindoor unit must not be exposed to rain or moisture.
• Never try to repair theproduct, dismantle or modify it in
anyway.
Buttons and functions
3. Plug thedoorbell into a230 V wall socket. Thedoorbell
will sound twice and theLED indicator (4) starts to flash
which indicates that thedoorbell is ready to be paired with
thetransmitter.
4. Within 30 seconds, press thetransmitter that you want
to connect thedoorbellto. Thedoorbell will sound
when thepairing has been successful. If you wish to
pair additional transmitters: Cutoff thepower supply to
thedoorbell, then repeat steps 3–4.
Selecting thering signal
Assembly
Informaon
• Avoid placing theunits next to metal objects such as metal
window frames as this may cause interference with reception.
• Test thedoorbell’s functionality/location before final mounting.
1. Doorbell/receiver
2. Button to select thevolume
3. Button to select the ring signal
4. LED indicator
5. Transmitter
6. Push Button Ring Signal
Installation
Handyp: One transmitter is included but you may connect
anadditional 7 transmitters (sold separately).
Battery/pairing theunits
1. Open thetransmitter carefully
by pressing thelatch with
ascrewdriver.
2. Remove theplastic tab from thebattery holder to activate
thebattery in theremote control.
Press [ ] repeatedly to select the ring signal. Youcan choose
between atotal of 16different melodies and sounds:
1. Dingdong
2. Für Elise
3. Westminster Chimes
4. Hey Jude
5. Swan Lake
6. Red River Valley
7. My heart will goon
8. Turkish March
9. Menuet
10. Hymn to Joy
11. William Tell Overture
12. Romance oflove
13. Memory
14. TheLittle Mermaid
15. Canon
16. Do re mi
Selecting thevolume
Press [ ] repeatedly to select the volume. Choose between
Hig, Medium, Low and Mute.
Remove thepaired transmitter
Informaon
If you follow thefollowing steps, it will remove all thepaired
transmitters from thedoorbell’s memory.
1. Dismantle one of thetransmitters.
2. Remove thepower supply to thedoorbell by disconnecting
it from thewall socket. Waitafew seconds and then plug it
in again so that thedoorbell is in pairingmode. Thedoorbell
will soundtwice.
3. While thedoorbell is in pairing mode, press thebutton
inside thetransmitter. Thedoorbell will sound to confirm that
all thetransmitters have been removed from thedoorbell’s
memory.
Care and maintenance
Clean theproduct using adampcloth. Useonly mild cleaning
agents, never solvents or corrosive chemicals.
Troubleshooting
No sound when
thepush button is
pressed.
• Check that thebatteries are inserted
correctly and that they are notflat.
• Excessive distance between
thetransmitter and thedoorbell.
1. Screw on or glue (with double-sided
adhesive tape) the backplate of
the transmitter to thewall.
2. Fit the transmitter onto the backplate,
making sure that thegasket is inplace.
Pressthe latch on the transmitter until
it clicks intoplace.
Responsible disposal
This symbol indicates that this product should not
be disposed of with general householdwaste.
Thisapplies throughout theentire EU. Inorder to
prevent any harm to theenvironment or health
hazards caused by incorrect waste disposal,
theproduct must be handed in for recycling so that
thematerial can be disposed of in aresponsible
manner. Whenrecycling theproduct, take it to your local
collection facility or contact theplace of purchase. Theywill
ensure that theproduct is disposed of in anenvironmentally
sound manner.
Specifications
Doorbell (receiver)
Rated voltage 230 V AC
Power consumpon ≤ 0.5 W
Range Up to 100 m (clear line of sight)
Noise level 78 dB (at adistance of 1 m)
Signals 16 different melodies and sounds
Size 70×70×67mm
Push button (transmitter)
Transmission frequency 433.92 MHz
Baery CR2032 lithium (3 V)
Size 35×17×85 mm
