E-15
Level Battery Power Indicator Function Status
3
(L)
Auto and manual receive, illumination,
beeper, sensor operation, tide level
indication, some Tide/Moon Mode
functions, some Fishing Mode functions,
and some Sunrise/Sunset Mode functions
disabled.
Second hand jumps every two seconds.
4
(CHARGE)
All hands stopped at 12 o’clock.
All functions disabled.
5 – – –
All hands stopped at 12 o’clock.
All functions disabled and settings return
to their initial factory defaults.
• The fl ashing
L
indicator at Level 3 (
L
) tells you that battery power is very low, and that exposure to
bright light for charging is required as soon as possible.
• Once the battery reaches Level 2 (
M
) after falling to Level 5, reconfi
gure the current time, date, and
other settings.
• Display indicators reappear as soon as the battery is charged from Level 5 to Level 2 (
M
).
E-14
Important!
• Allowing the watch to become very hot can cause its liquid crystal display to go blank (totally black or
totally white, depending on the watch model). The appearance of the LCD should become normal
again when the watch returns to a lower temperature.
• Turn on the watch’s Power Saving function (page E-19) and keep it in an area normally exposed to bright
light when storing it for long periods. This helps to ensure that power does not run down.
• Storing the watch for long periods in an area where there is no light or wearing it in such a way that it is
blocked from exposure to light can cause power to run down. Expose the watch to bright light
whenever possible.
Power Levels
Hold down
B
for at least two seconds to enter the Timekeeping Mode.
You can get an idea of the watch’s power level by observing the battery power indicator on the display.
Level Battery Power Indicator Function Status
1
(H)
All functions enabled.
2
(M)
All functions enabled.
Battery power
indicator
E-13
Charging the Watch
The face of the watch is a solar panel that generates power from light. The generated power charges a
built-in rechargeable battery, which powers watch operations. The watch charges whenever it is exposed
to light.
Charging Guide
Whenever you are not wearing the
watch, leave it in a location where it
is exposed to light.
• Best charging performance is
achieved by exposing the watch to
the strongest light available.
When wearing the watch, make sure
that its face is not blocked from light
by the sleeve of your clothing.
• The watch may enter a sleep state
(page E-19) if its face is blocked by
your sleeve even only partially.
Warning!
Leaving the watch in bright light for charging can cause it to become quite hot.
Take care when handling the watch to avoid burn injury. The watch can become particularly hot
when exposed to the conditions below for long periods.
•
On the dashboard of a car parked in direct sunlight
• Too close to an incandescent lamp
• Under direct sunlight
E-12
Checking the Current Time in a Different Time Zone ………………………………………………… E-112
To enter the World Time Mode …………………………………………………………………… E-112
To confi gure World Time City and summer time settings ……………………………………… E-113
To swap your Home City and World Time City …………………………………………………… E-115
To access the UTC (Universal Time Coordinated) time zone ………………………………… E-115
Illumination ………………………………………………………………………………………………… E-116
To turn on illumination manually …………………………………………………………………… E-116
To change the illumination duration ……………………………………………………………… E-116
To enable or disable the auto light switch ………………………………………………………… E-118
Other Settings ……………………………………………………………………………………………… E-120
To enable or disable the button operation tone ………………………………………………… E-120
To enable or disable Power Saving ……………………………………………………………… E-120
Troubleshooting …………………………………………………………………………………………… E-121
Specifi cations ……………………………………………………………………………………………… E-129
E-11
Looking up Sunrise and Sunset Times ………………………………………………………………… E-102
To enter the Sunrise/Sunset Mode ………………………………………………………………… E-102
To view the sunrise/sunset time for a particular date …………………………………………… E-103
To look up the sunrise and sunset times for a specifi c location ………………………………… E-103
Using the Stopwatch ……………………………………………………………………………………… E-105
To enter the Stopwatch Mode ……………………………………………………………………… E-105
To perform an elapsed time operation …………………………………………………………… E-105
To pause at a split time ……………………………………………………………………………… E-105
To measure two fi nishes …………………………………………………………………………… E-106
Using the Countdown Timer ……………………………………………………………………………… E-107
To enter the Countdown Timer Mode ……………………………………………………………… E-107
To specify the countdown start time ……………………………………………………………… E-107
To perform a countdown timer operation ………………………………………………………… E-108
To stop the alarm …………………………………………………………………………………… E-108
Using the Alarm …………………………………………………………………………………………… E-109
To enter the Alarm Mode …………………………………………………………………………… E-109
To set an alarm time ………………………………………………………………………………… E-110
To turn an alarm and the Hourly Time Signal on and off………………………………………… E-111
To stop the alarm tone ……………………………………………………………………………… E-111
To test the alarm tone ……………………………………………………………………………… E-111
E-10
Taking Barometric Pressure Readings ………………………………………………………………… E-75
To take barometric pressure readings …………………………………………………………… E-75
To specify the barometric pressure auto measurement interval ……………………………… E-78
To enable barometric pressure differential indication by the small hand ……………………… E-78
To enable or disable the barometric pressure change indicator ……………………………… E-81
To calibrate the pressure sensor …………………………………………………………………… E-83
Taking Temperature Readings …………………………………………………………………………… E-84
To take temperature readings ……………………………………………………………………… E-84
To calibrate the temperature sensor ……………………………………………………………… E-85
Viewing Altitude Records ………………………………………………………………………………… E-87
To view altitude records …………………………………………………………………………… E-87
To delete a specifi c record ………………………………………………………………………… E-90
To delete all recorded data ………………………………………………………………………… E-90
Checking the Tide Level and Moon Ages (Tide/Moon) ……………………………………………… E-91
To view the current tide level and Moon age……………………………………………………… E-91
To view the tide level and Moon age for a specifi c date and time ……………………………… E-93
To calibrate the high tide time ……………………………………………………………………… E-95
Viewing Favorable Fishing Times ……………………………………………………………………… E-97
To view today’s fi shing times ……………………………………………………………………… E-97
To display the fi shing time for a specifi ed date …………………………………………………… E-99
To turn the fi shing time alarm on or off …………………………………………………………… E-99
E-9
Moving the Hands for Easy Viewing of the Digital Display ………………………………………… E-42
To shift the hands and view digital info …………………………………………………………… E-42
To return the hands to their normal positions …………………………………………………… E-43
Taking Direction Readings ……………………………………………………………………………… E-44
To take a direction reading ………………………………………………………………………… E-45
To perform fi gure 8 calibration ……………………………………………………………………… E-48
To perform 3-point calibration ……………………………………………………………………… E-50
To perform magnetic declination correction ……………………………………………………… E-53
To store a direction angle reading in Bearing Memory ………………………………………… E-54
Specifying Altitude, Barometric Pressure, and Temperature Units ……………………………… E-58
To specify altitude, barometric pressure, and temperature units ……………………………… E-58
Using the Altimeter Mode ………………………………………………………………………………… E-59
To specify the altitude auto reading interval ……………………………………………………… E-60
To take altitude readings …………………………………………………………………………… E-61
To specify a reference altitude value ……………………………………………………………… E-63
To specify the altitude differential measurement range ………………………………………… E-65
To use the altitude differential value ……………………………………………………………… E-66
To save a reading manually ………………………………………………………………………… E-68
Precautions Concerning Simultaneous Altitude and Temperature Readings ………………… E-74
E-8
Contents
About This Manual …………………………………………………………………………………………… E-2
Using the Crown ……………………………………………………………………………………………… E-3
Things to check before using the watch ………………………………………………………………… E-6
Charging the Watch ………………………………………………………………………………………… E-13
To recover from the sleep state …………………………………………………………………… E-19
Radio Controlled Atomic Timekeeping ………………………………………………………………… E-20
To get ready for a receive operation ……………………………………………………………… E-22
To perform manual receive ………………………………………………………………………… E-24
To check the latest signal reception results ……………………………………………………… E-27
To turn auto receive on or off ……………………………………………………………………… E-28
Mode Reference Guide …………………………………………………………………………………… E-30
Timekeeping ………………………………………………………………………………………………… E-35
Confi guring Home City Settings ………………………………………………………………………… E-36
To confi gure Home City and summer time settings ……………………………………………… E-36
Confi guring Current Time and Date Settings Manually ……………………………………………… E-38
To change the current time and date settings manually ………………………………………… E-38
To switch between 12-hour and 24-hour timekeeping …………………………………………… E-40
Hand Home Position Adjustment ……………………………………………………………………… E-41
To trigger hand home position adjustment manually …………………………………………… E-41
Operation Guide 5480
