Operation Guide 5590

E-39

Illumination

The display of the watch is illuminated for easy reading in the dark.

To turn on illumination

Press L in any mode to illuminate the display.

x You can use the procedure below to select either 1.5 seconds or three seconds as

the illumination duration.

Note

x The LED light will turn off automatically if the alarm starts to sound.

x The LED light is disabled while the hands are moving at high speed.

E-38

To turn an alarm and the Hourly Time Signal on and off

In the Alarm Mode, use D and B to select an alarm or

the hourly time signal.

x When the alarm you want or the Hourly Time Signal

is displayed, press A to toggle it between on

(ON displayed) and off (– – displayed).

x The alarm on indicator (when any alarm is on) and the

Hourly Time Signal on indicator (when the Hourly Time

Signal is on) are shown on the display in all modes.

To stop the alarm

Press any button.

Hourly time signal

on indicator

Alarm on indicator

E-37

3. Press C to move the flashing between the hour and the minute digits.

x The selected digits are those that are flashing.

4. Use D (+) and B (–) to change the hour and minute settings.

x When setting the alarm time using the 12-hour format, take care to set the time

correctly as a.m. (no indicator) or p.m. (P indicator).

5. Press A to exit the setting mode.

To test the alarm

In the Alarm Mode, hold down D to sound the alarm.

E-36

x If you do not perform any operation for about two or three minutes in the Alarm

Mode, the watch will automatically return to the Timekeeping Mode.

To set an alarm time

1. In the Alarm Mode, use D and B to display the alarm

whose settings you want to change.

AL1 AL3AL2

AL5SIG AL4

2. Hold down A until the flashing SET indicator

disappears from the display and the alarm time hour

digits start to flash. Release A after the digits start

to flash.

x ALM appears on the display, indicating that alarm

setting is enabled.

Alarm on indicator

E-35

Using the Alarm

You can set five independent daily alarms. When a daily

alarm is turned on, an alarm tone will sound for about

10seconds each day when the time in the Timekeeping

Mode reaches the preset alarm time.

You can also turn on an Hourly Time Signal, which will

cause the watch to beep twice every hour on the hour.

To enter the Alarm Mode

Use C to select the Alarm Mode as shown on page

E-11.

x Alarm screens are numbered AL1 through AL5. The

Hourly Time Signal screen is indicated by SIG.

x When you enter the Alarm Mode, the data you were

viewing when you last exited the mode appears first.

Alarm number

Alarm time

(Hour : Minute)

E-34

To perform a countdown timer operation

D

D D D B

Start Stop (Resume) (Stop) Reset

Countdown in Progress

To stop the alarm

Press any button.

E-33

To configure the countdown timer

x If a countdown timer operation is in progress, press D

to pause it and then press B to reset the timer to its

start time.

x If a countdown timer operation is paused, press B to

reset the timer to its start time.

1. Hold down A until the flashing SET indicator

disappears from the display and the hour digits start to

flash. Release A after the digits start to flash.

2. Each press of C cause the flashing to move between settings in the following

sequence: Hours

Minutes Seconds.

x The flashing value is the one that is currently selected for setting.

3. Use D (+) and B (–) to change the currently flashing value.

4. Press A to exit the setting mode.

E-32

Countdown Timer

The countdown timer start time can be set in 1-second

increments up to a maximum of 24hours. An alarm

sounds when the countdown reaches zero.

To enter the Countdown Timer Mode

Use C to select the Countdown Timer Mode as shown

on page E-11.

Minutes

Seconds

Hours

E-31

Note

x An ongoing elapsed time measurement operation will continue internally even if

you change to another mode. However, if you exit the Stopwatch Mode while a

split time is displayed, the split time will not be displayed when you return to the

Stopwatch Mode.

E-30

x Elapsed time is shown in 1/100-second units for the first hour of the measurement.

After the first hour, elapsed time is shown in one-second units.

First hour After first hour

Seconds Minutes

Minutes Hours

1/100 Second Seconds
