Operation Guide 2548/2821

1

MA0309-EA

About This Manual

• The operational procedures for Modules 2548 and 2821

are identical. All of the illustrations in this manual show

Module 2548.

• Button operations are indicated using the letters shown

in the illustration.

• Each section of this manual provides you with the

information you need to perform operations in each

mode. Further details and technical information can be

found in the “Reference” section.

Module 2821

(Light)

Module 2548

• Module 2821 does not display an AM indicator (A).

General Guide

• Press C to change from mode to mode.

• In any mode, press L to illuminate the display.

Timekeeping Mode World Time Modee-DATA MEMORY Mode Stopwatch ModeCountdown Timer ModeAlarm Mode

Press .

City code

Timekeeping

Use the Timekeeping Mode to set and view the current

time and date.

Read This Before You Set the Time and Date !

The times displayed in the Timekeeping Mode and World

Time Mode are linked. Because of this, make sure you

select a city code for your Home City (the city where you

normally use the watch) before you set the time and date.

Seconds

Hour : Minutes

PM indicator

Day of week

Month – Day

To set the time and date

1. In the Timekeeping Mode, hold down A until the

seconds start to flash, which indicates the setting

screen.

2. Press C to move the flashing in the sequence shown

below to select other settings.

Minutes

12/24-Hour

Format

Seconds City Code

Hour

YearDay

DST

Month

3. When the setting you want to change is flashing, use D and B to change it as

described below.

Screen

50

OFF

TYO

P

10:58

12H

2003

6-30

To do this:

Reset the seconds to

00

Toggle between Daylight Saving Time (

0N

)

and Standard Time (0FF)

Change the city code

Change the hour or minutes

Toggle between 12-hour (

12H

) and 24-hour

(24H) timekeeping

Change the year

Change the month or day

Do this:

Press D.

Press D.

Use

D (east) and B (west).

Use

D (+) and B (–).

Press D.

Use

D (+) and B (–).

•

For full information on city codes, see the “City Code Table”.

• See “Daylight Saving Time (DST)” for details about DST setting.

4. Press A to exit the setting screen.

• With the 12-hour format, the P (PM) indicator appears on the display for times in the

range of noon to 11:59 p.m. and the A (AM) indicator appears for times in the range

of midnight to 11:59 a.m. Note that Module 2821 does not display an AM indicator

(A).

• With the 24-hour format, times are displayed in the range of 0:00 to 23:59, without

any indicator.

• The 12-hour/24-hour timekeeping format you select in the Timekeeping Mode is

applied in all modes.

• The day of the week is automatically displayed in accordance with the date (year,

month, and day) settings.

Daylight Saving Time (DST)

Daylight Saving Time (summer time) advances the time setting by one hour from Standard

Time. Remember that not all countries or even local areas use Daylight Saving Time.

To toggle the Timekeeping Mode time between DST and Standard Time

1. In the Timekeeping Mode, hold down A until the

seconds start to flash, which indicates the setting

screen.

2. Press C to display the DST setting screen.

3. Press D to toggle between Daylight Saving Time

(

ON

displayed) and Standard Time (

OFF

displayed).

• Note that you cannot switch between Standard Time

and Daylight Saving Time while

GMT is selected as

the Home City code.

4. Press A to exit the setting screen.

• The DST indicator appears on the display to indicate

that Daylight Saving Time is turned on.

e-DATA MEMORY

You can use the watch’s e-DATA MEMORY to store e-mail

addresses, Web page URLs, and other text data.

You can also use a password to limit access to e-DATA

MEMORY contents.

• All of the operations in this section are performed in the

e-DATA MEMORY Mode, which you enter by pressing

C.

e-DATA MEMORY Management

e-DATA MEMORY can hold up to 315 characters total,

while each record can contain up to 63 characters. The

maximum number of records depends on the number of

characters per record, as shown below.

• 63 characters per record: 5 records

• 7 or fewer characters per record: 40 records

To create a new e-DATA MEMORY record

1. In the e-DATA MEMORY Mode, press D and B at the

same time to display the remaining memory screen.

• If

0

% is shown for remaining memory, it means that

memory is full. To store another record, you will first

have to delete some of the records stored in memory.

2. Hold down A until the flashing cursor (

#

) appears on

the display, which indicates the setting screen.

• The setting screen also shows the record number that

is automatically assigned to the new record.

3. Input the text you want.

• When inputting the text, use D (+) and B (–) to

cycle through characters at the current cursor

location, and C to move the cursor to the right. See

“Inputting Text”.

Record number

(Page number)

Text

Remaining memory (%)

4. Press A to store your data and return to the e-DATA MEMORY record screen

(without the cursor).

• Pressing A causes the message

SET to appear for about two seconds as the

data is stored. After that, the e-DATA MEMORY record screen appears.

• The text can show only three characters at a time, so longer text scrolls

continuously from right to left. The last character is indicated by the symbol

s after

it. Press A to stop and restart scrolling.

• Records are stored in memory in the sequence they are created.
