Operation Guide 5632

MA1907-EA

© 2019 CASIO COMPUTER CO., LTD.

Rotate the Crown towards you to

set the day.

Push the Crown back in on a time

signal to resume timekeeping.

To change the day indicator setting

To adjust the time setting

Pull the Crown out to Click 1.

Push the Crown back in.

Rotate the Crown to change the

time setting.

When the second hand is at

12 o’clock, pull the

Crown out to

Click 2.

Note

x

Take care that you set the correct AM

or PM time.

x

When changing the time, move the

minute hand four or fi ve minutes past

your fi nal setting, and then back it up

to the setting you want.

Note

x

The day indicator setting uses a 31-

day month. Make adjustments for

months of shorter lengths.

x

Avoid changing the day indicator

setting between the hours of 9

p.m. and 1 a.m. Otherwise, the day

indicator may not change correctly at

midnight.

Stopwatch functions

Crown Operations

Some water-resistant models (100 meters, 200 meters)

have a screw-in crown. When you need to perform a crown

operation, rotate it towards you to unscrew it. Then pull

the crown out. Avoid applying undue force when pulling.

The watch loses its water resistance while the crown is

unscrewed. After performing a crown operation, fully screw

the crown back in.

Crown

Loosen

If your watch has a rotary bezel...

You can rotate the bezel to align its

▼

mark with the

minute hand. Then you will be able to tell how much

time has elapsed since aligning the

▼

mark.

Start

Elapsed time

Current

Low Battery Alert

x

The second hand will jump at two-second intervals to alert you when the charge is low.

x

Have the battery replaced as soon as possible after low battery alert is indicated.

x

Stopwatch operation is disabled during low battery alert.

x If low battery alert occurs during a stopwatch operation, the stopwatch will

automatically reset to all zeros and stop.

x Be sure to keep all user documentation handy for future reference.

x Your watch may differ somewhat from the one shown in the illustration.

Day Indicator

30

Second Hand

Stopwatch Minute Hand

Hour Hand

24-Hour Hand

Minute Hand

B

A

Crown

Click 2

Click 1

Stopwatch Second Hand

Specifi cations

Module No.

Accuracy at normal

temperature (per month)

Battery type

Battery life

(30 minutes stopwatch

operation per day)

5632 ±20 seconds SR920SW Approx. 3 years

Stopwatch: Measuring Capacity: 29'59" (30 minutes)

Measuring Unit: 1 second

Measurements: Elapsed time; split time; two fi nishes

Other: Low battery alert

Specifi cations are subject to change without notice.

Perform the following procedure if the stopwatch hands do not return to their 0 (zero)

positions when you reset the stopwatch.

Correcting the 0 Positions of the Hands

Pull the Crown out to Click 2.

Use A (clockwise) and B (counterclockwise) to move the

Stopwatch Second Hand

and

Stopwatch Minute Hand

to 12 o'clock.

x Holding down either button will move the second hand at high speed, until you

release the button.

x The

Stopwatch Minute Hand

is syncronized with the

Stopwatch Second Hand

.

After all of the hands are the way you want, push the Crown back in.

Important!

x

Timekeeping stops while the crown is pulled out. Correct the current time setting

after performing the above operation.

Using the Stopwatch

Important!

x

Do not operate the stopwatch with the crown pulled out.

Note

x

An elapsed time operation will stop automatically at the end of 30 minutes.

The stopwatch measures elapsed time in 1-second increments up to 29minutes,

59seconds.

Elapsed time

A

A

A A

B

Start Stop Resume Stop Reset

Split time

A

B

B A

B

Start Split Split release Stop Reset

Two fi nishes

A

B

A B

B

Start Split

First runner

fi nishes.

Display time of

fi rst runner.

Stop

Second runner

fi nishes.

Split release

Display time of

second runner.

Reset
