Operation Guide 5633

E-19

Specifications

Accuracy at normal temperature: ±20 seconds a month

Stopwatch: Measuring Capacity: 29'59" (30minutes)

Measuring Unit: 1 second

Measurements: Elapsed time; split time; two finishes

Other: Low battery alert

Power Supply: Solar panel and one rechargeable battery

Approximate battery operating time: 6months (no exposure to light after a full

charge)

Specifications are subject to change without notice.

E-18

Abnormal Hand Movement or Function

Should the watch ever exhibit abnormal hand movement or function, or if the second

hand does not move normally (one-second increments) even after the watch is fully

charged, perform the procedure below to perform a system reset.

1. Pull the

Crown out to Click 2.

2. Hold down both A and B for at least two seconds.

3. Push the

Crown back in.

x The second hand will start to move.

4. As required, correct the current time and day settings (page E-12), and

correct stopwatch hand alignment if necessary (page E-16).

Important!

x Timekeeping stops while the crown is pulled out. Correct the current time setting

after performing the above operation.

E-17

Important!

x Timekeeping stops while the crown is pulled out. Correct the current time setting

after performing the above operation.

E-16

Correcting Stopwatch Hand Alignment

Perform the following procedure if the stopwatch hands do not return to their home

positions (12 o’clock or L) when you reset the stopwatch.

1. When the second hand is at 12o’clock, pull the

Crown out to Click 2.

2. Hold down A for at least two seconds.

x The Stopwatch Minute Hand will rotate to indicate the minute hand setting mode.

x If the hand does not align with L, use the B button to adjust it.

x Holding down B moves the current hand at high speed.

3. Press A.

x The Stopwatch Second Hand will perform one full rotation to indicate the second

hand setting mode.

x If the hand does not align with 12o’clock, use the B button to adjust it.

x Holding down B moves the current hand at high speed.

4. After all of the hands are the way you want, push the

Crown back in.

E-15

Two finishes

A

B A B B

Start Split

First runner

finishes.

Display time of

first runner.

Stop

Second runner

finishes.

Split release

Display time of

second runner.

Reset

Important!

x Do not operate the stopwatch with the crown pulled out.

Note

x An elapsed time operation will stop automatically at the end of 30minutes.

E-14

Using the Stopwatch

The stopwatch measures elapsed time in 1-second increments up to 29minutes,

59seconds.

Elapsed time

A

A A A B

Start Stop Resume Stop Reset

Split time

A

B B A B

Start Split Split release Stop Reset

E-13

To change the day indicator setting

1. Pull the Crown out to Click 1.

2. Rotate the Crown away from you to set the day.

3. Push the Crown back in.

Note

x The day indicator setting uses a 31-day month. Make adjustments for months of

shorter lengths.

x Avoid changing the day indicator setting between the hours of 9 p.m. and 1 a.m.

Otherwise, the day indicator may not change correctly at midnight.

E-12

Setting the Current Time and Day

To adjust the time setting

1. When the second hand is at 12o’clock, pull the Crown out to Click 2.

2. Rotate the

Crown to change the time setting.

3. Push the Crown back in on a time signal to resume timekeeping.

Note

x Take care that you set the correct AM or PM time.

x When changing the time, move the minute hand four or five minutes past your final

setting, and then back it up to the setting you want.

E-11

Indicators and Crown Operation

30

A

B

Click 2

Click 1

Crown

Day Indicator

Hour Hand

Minute Hand

Battery Level Hand / Stopwatch Minute Hand

Stopwatch functions

Second Hand

Stopwatch Second Hand

E-10

Charging Time Required to Restore Operation from a Dead Battery

Exposure Level

(Brightness)

Approximate Charging

Time to 1-second

Hand Movement

Approximate Time to

Full Charge

Outdoor sunlight (50,000 lux) 4 hours 14 hours

Sunlight through a window

(10,000 lux)

11 hours 66 hours

Daylight through a window on

an overcast day (5,000 lux)

14 hours 114 hours

Indoor fluorescent lighting

(500 lux)

195 hours – – –

Note

x Actual charging time depends on environmental conditions.
