Operation Guide 3455

E-28

Power Supply: One lithium battery (Type: CR1620)

Approximate battery operating time: 10 years under the following conditions:

x One alarm operation (10 seconds) per day

x One illumination operation (1.5 seconds) per day

Frequent use of illumination runs down the battery.

Specifications are subject to change without notice.

E-27

Specifications

Accuracy at normal temperature: ±20 seconds a month

Timekeeping: Hour, minutes, seconds, p.m. (P), month, day, day of the week

Time format: 12-hour and 24-hour

Calendar system: Full Auto-calendar pre-programmed from the year 2000 to 2099

Alarms: Daily alarm; Hourly time signal

Stopwatch:

Measuring unit: 1/100 second

Measuring capacity: 23:59' 59.99"

Measuring modes: Elapsed time, split time, two finishes

Dual Time: Hour, minutes

Illumination: LED (light-emitting diode); Selectable illumination duration

(approximately 1.5 seconds or 3 seconds)

E-26

Main Indicators

Number Name See

1

1

24 indicator E-14

2

2

PM indicator E-11

3

3

Alarm on indicator E-16, E-17

4

4

Hourly time signal on indicator E-17

5

5

SPL indicator E-20

6

6

Three-second indicator E-25

1 2

4 53 6

E-25

To change the illumination duration

In the Timekeeping Mode, hold down C for at least two seconds to toggle between

the illumination duration settings below.

− Approximately 1.5 seconds: 3"-second indicator not displayed.

− Approximately three seconds: 3"-second indicator displayed.

x Pressing C in the above operation also toggles between the 12-hour and 24-hour

timekeeping formats.

x To prevent running down the battery, the watch will

automatically switch back to the 1.5-second setting

about seven hours after you select the three-second

setting.

Three-second indicator

E-24

Illumination

You can illuminate the display of the watch for easy reading in the dark.

To turn on illumination

Press L in any mode to illuminate the display.

x Illumination normally remains on for about 1.5 seconds. You can use the procedure

below to change the illumination to three seconds.

Note

x Illumination turns off automatically whenever an alarm sounds.

E-23

3. Use C to change the hour and minute settings.

4. Press A to exit the setting mode.

x In the Dual Time Mode, the seconds count is synchronized with the seconds

count of the Timekeeping Mode.

E-22

Dual Time Mode

The Dual Time Mode lets you keep track of the time

in another time zone.

x The P (PM) and 24 indicators are not displayed with

the current (Timekeeping Mode) time at the top of

the Dual Time Mode screen.

To enter the Dual Time Mode

Use B to select the Dual Time Mode as shown on

page E-9.

To set the Dual Time

1. Hold down A until the dual time hour digits start

to flash.

2. Press B to move the flashing between the hour

and the minute digits.

x The selected digits are those that are flashing.

Mode indicator

Timekeeping Mode time

(Hour : Minutes)

Hour : Minute

Seconds

E-21

To measure two finishes

C

A C A A

Start Split

(SPL displayed)

First runner finishes.

Display time of first

runner.

Stop

Second runner

finishes.

Split release

Display time of

second runner.

Reset

Note

x An ongoing elapsed time measurement operation will continue internally even if

you change to another mode. However, if you exit the Stopwatch Mode while a

split time is displayed, the split time will not be displayed when you return to the

Stopwatch Mode.

E-20

To enter the Stopwatch Mode

Use B to select the Stopwatch Mode as shown on page E-9.

To perform an elapsed time operation

C

C C C A

Start Stop (Resume) (Stop) Reset

To pause at a split time

C

A A C A

Start Split

(SPL displayed)

Split release Stop Reset
