Operation Guide 2672

1

About This Manual

• Button operations are indicated using the letters shown

in the illustration.

• Each section of this manual provides you with the

information you need to perform operations in each

mode. Further details and technical information can be

found in the “Reference” section.

Timekeeping Mode

Alarm Mode Stopwatch Mode Dual Time Mode

Press .

General Guide

• Press B to change from mode to mode.

• In any mode, press L to illuminate the display.

Day of week

Seconds

Hour : Minutes

PM indicator

Month – Day

Timekeeping

Use the Timekeeping Mode to set and view the current

time and date.

To set the time and date

1. In the Timekeeping Mode, hold down A until the

seconds start to flash, which indicates the setting

screen.

2. Press B to move the flashing in the sequence shown

below to select other settings.

Seconds Hour

Minutes

YearMonthDay of week Day

3. When the setting you want to change is flashing, press C to change it as

described below.

To change this setting

Seconds

Hour, Minutes, Year, Month,

Day, Day of week

Perform this button operation

Press C to reset to 00.

Press C to increase the setting.

Holding down C changes the setting at high speed.

• Pressing C while the seconds are in the range of 30 to 59 resets them to 00 and

adds 1 to the minutes. In the range of 00 to 29, the minutes are unchanged.

4. Press A to exit the setting screen.

• The year can be set in the range of 2000 to 2099.

• The watch’s built-in full automatic calendar automatically makes allowances for

different month lengths and leap years. Once you set the date, there should be no

reason to change it except after you have the watch’s battery replaced.

To toggle between 12-hour and 24-hour timekeeping

In the Timekeeping Mode, press C to toggle between 12-hour timekeeping and

24-hour timekeeping.

• With the 12-hour format, the P (PM) indicator appears to the left of the hour digits for

times in the range of noon to 11:59 p.m. and no indicator appears to the left of the

hour digits for times in the range of midnight to 11:59 a.m.

• With the 24-hour format, (24 indicator), times are displayed in the range of 0:00 to

23:59.

• The P and 24 indicators are not displayed with the Timekeeping Mode time in the

Alarm Mode and Dual Time Mode.

• The 12-hour/24-hour timekeeping format you select in the Timekeeping Mode is

applied in all other modes.

Alarm

When the daily alarm is turned on, the alarm tone sounds

when the alarm time is reached.

You can also turn on an Hourly Time Signal that causes

the watch to beep twice every hour on the hour.

• Alarm setting (and Hourly Time Signal setting) is

available in the Alarm Mode, which you enter by

pressing B.

Alarm Operation

The alarm tone sounds at the preset time for 10 seconds,

regardless of the mode the watch is in.

Alarm time

(Hour : Minutes)

Timekeeping Mode tim

e

(Hour : Minutes)

Mode indicator

Hourly time signal

on indicator

Alarm on indicator

To set an alarm time

1. In the Alarm Mode, hold down A until the hour setting

starts to flash, which indicates the setting screen.

• This operation automatically turns on the alarm.

2. Press B to move the flashing between the hour and

minutes.

3. While a setting is flashing, use C to increase it.

Holding down C changes the setting at high speed.

• With the 12-hour format, set the time correctly as a.m.

(no indicator) or p.m. (P indicator).

4. Press A to exit the setting screen.

To stop the alarm tone after it starts to sound

Press any button.

To turn the Daily Alarm and Hourly Time Signal on and off

In the Alarm Mode, press C to cycle through the on and

off settings as shown below.

Alarm On Indicator/Hourly Time Signal On Indicator

Daily alarm

only

Both off

Both on Hourly Time

Signal only

• The alarm on (ALM) indicator flashes while the alarm is

sounding.

• The alarm on (ALM) indicator and Hourly Time Signal

on (SIG) indicator are displayed in all modes.

To test the alarm

In the Alarm Mode, hold down C to sound the alarm.

Stopwatch

The stopwatch lets you measure elapsed time, split times,

and two finishes.

• The display range of the stopwatch is 23 hours,

59 minutes, 59.99 seconds.

• The stopwatch continues to run, restarting from zero

after it reaches its limit, until you stop it.

• The stopwatch measurement operation continues even

if you exit the Stopwatch Mode.

• Exiting the Stopwatch Mode while a split time is frozen

on the display clears the split time and returns to

elapsed time measurement.

• All of the operations in this section are performed in the

Stopwatch Mode, which you enter by pressing B.

To measure times with the stopwatch

Elapsed time

Start Stop Re-start Stop Clear

Start

Split

(SPL displayed)

Split release Stop Clear

Start

Split Stop Split release Clear

Split time

Two Finishes

First runner

finishes.

Display time of

first runner.

Second runner

finishes.

Display time of

second runner.

Minutes

1/100 second

Mode indicator

Hours

Seconds

Dual Time

The Dual Time Mode lets you keep track of time in a different time zone.

• In the Dual Time Mode, the seconds count is synchronized with the seconds count

of the Timekeeping Mode.

To set the Dual Time

1. Press B to enter the Dual Time Mode.

2. Hold down A until the hour setting starts to flash,

which indicates the setting screen.

3. Press B to move the flashing between the hour and

minutes settings.

4. Press C to increase the setting. Holding down C

changes the setting at high speed.

5. Press A to exit the setting screen.

Timekeeping Mode time

(Hour : Minutes)

Mode indicator

Seconds

Hour : Minutes

MA0307-EA
