Operation Guide 3426

E

About This Manual

 Depending on the model of your watch, display text

appears either as dark fi gures on a light background or

light fi gures on a dark background. All sample displays

in this manual are shown using dark fi gures on a light

background.

 Button operations are indicated using the letters shown

in the illustration.

 Each section of this manual provides you with the

information you need to perform operations in each

mode. Further details and technical information can be

found in the “Reference” section.

 To ensure that this watch provides you with the years of

service for which it is designed, be sure to carefully read

and follow the instructions under “Operating Precautions”

and “User Maintenance”.

 Be sure to keep all user documentation handy for future

reference.

-ANUFACTURER

#!3)/#/-054%2#/,4$

(ONMACHICHOME3HIBUYAKU4OKYO*APAN

2ESPONSIBLEWITHINTHE%UROPEAN5NION

#!3)/%52/0%'MB(

#ASIO0LATZ.ORDERSTEDT'ERMANY

MA1310-EA

© 2013 CASIO COMPUTER CO., LTD.

E-1

Contents

General Guide .......................................................................................................... E-4

Timekeeping ............................................................................................................. E-6

Stopwatch .............................................................................................................. E-11

Preset Timer ........................................................................................................... E-16

Countdown Timer .................................................................................................. E-20

World Time ............................................................................................................. E-26

Alarm ...................................................................................................................... E-28

Illumination ............................................................................................................ E-31

Reference ............................................................................................................... E-32

Specifi cations ........................................................................................................ E-38

Operating Precautions .........................................................................................E-m1

User Maintenance ...............................................................................................E-m11

E-2

Procedure Lookup

The following is a handy reference list of all the operational procedures contained in

this manual.

To set the time and date ......................................................................................... E-7

To toggle the Timekeeping Mode time between DST and Standard Time ......... E-9

To toggle between 12-hour and 24-hour timekeeping ....................................... E-10

To measure times with the stopwatch ................................................................. E-12

To set the event time ............................................................................................. E-14

To start timing at the beginning of an event ....................................................... E-14

To pause timing ..................................................................................................... E-15

To reset elapsed time measurement to zero ....................................................... E-15

To perform a preset timer operation .................................................................... E-17

To confi gure countdown timer settings .............................................................. E-21

To perform a countdown timer operation ........................................................... E-24

E-3

To view the time for another city code ................................................................ E-26

To toggle a city code time

between Standard Time and Daylight Saving Time ........................................ E-27

To set the alarm time ............................................................................................. E-28

To stop the alarm tone after it starts to sound .................................................. E-29

To switch the Daily Alarm and Hourly Time Signal on and off ......................... E-30

To test the alarm .................................................................................................... E-30

To illuminate the display ....................................................................................... E-31

To turn the button operation tone on and off ..................................................... E-34

E-4

General Guide

 Press C to change from mode to mode.

 In any mode (except when a setting screen is on the display), press B to illuminate

the display.

C

Timekeeping Mode

C C

Stopwatch Mode Preset Timer Mode

E-5

C

C C

Countdown Timer Mode World Time Mode Alarm Mode

E-6

Timekeeping

Use the Timekeeping Mode to set and view the current

time and date.

Read This Before You Set the Time and Date !

The times displayed in the Timekeeping Mode and World

Time Mode are linked. Because of this, make sure you

select a city code for your Home City (the city where you

normally use the watch) before you set the time and date.

 For full information on city codes, see the “City Code

Table” at the back of this manual.

Hour : Minutes

PM indicator

Day of week

Seconds

Month – Day

E-7

To set the time and date

1. In the Timekeeping Mode, hold down A until the

seconds start to fl ash, which indicates the setting

screen.

2. Press C to move the fl ashing in the sequence shown

below to select other settings.

Seconds DST City Code Hour

C C C C

C

Day

Month Year Minutes

C C C

E-8

3. When the setting you want to change is fl ashing, use D and B to change it as

described below.

Screen To do this: Do this:

Reset the seconds to

Press D.

Toggle between Daylight Saving Time ( )

and Standard Time ( )

Change the city code

Use D (east) and B (west).

Change the hour or minutes

Use D (+) and B (–).

Change the year

Change the month or day

 See “Daylight Saving Time (DST)” on page E-9 for details about the DST setting.

4. Press A to exit the setting screen.

E-9

Daylight Saving Time (DST)

Daylight Saving Time (summer time) advances the time setting by one hour from

Standard Time. Remember that not all countries or even local areas use Daylight

Saving Time.

To toggle the Timekeeping Mode time between DST and Standard Time

1. In the Timekeeping Mode, hold down A until the

seconds start to fl ash, which indicates the setting

screen.

2. Press C to display the DST setting screen.

3. Press D to toggle between Daylight Saving Time (

displayed) and Standard Time (

displayed).

4. Press A to exit the setting screen.

 The DST indicator is on the display while Daylight Saving

Time is turned on.

DST indicator
