Bruksanvisning

1. Check package contents to ensure that all parts are

enclosed and in good condition (see pictures below).

2. Test light tubes to ensure that all three are in

working order.

Check Package Contents

Your Day-Light comes with the following components:

The light case, which includes three pre-installed

light tubes and a built-in stand on the back;

Two height-adjustable legs (see photo). Note the

placement of the Height Adjustment Button;

Users Guide and your Warranty Registration Card.

Please check to see that all parts are included in your

package. Send in your Warranty Card today to ensure

you are registered. Contact your dealer if any product

parts are missing or damaged.

Test Light Tubes

Your Day-Light comes equipped with three 36 watt

compact fluorescent light tubes and can be used in a

two-or three-light setting. Test to see that the switch

and light tubes are working properly with these steps:

Plug in the light case.

Push the switch to the solid yellow dot for the three-

light setting. The lamp should illuminate.

Push the switch to the yellow “O” for the two-light

setting. The lamp should illuminate at a lower

intensity.

If all three tubes do not light up, the non-functioning

light may be loose or damaged.

www.day-lights.com

In this event, you will need to remove and reinstall the

nonfunctioning light tube to determine the problem, as

described in the section

Removing and Installing

Day-Light Tubes

below.

Removing & Installing Day-Light Tubes

1. Unplug the Day-Light (remove both detachable legs

if already assembled).

2. Gently lay the lamp with lens down on a flat surface.

3. Remove the nine screws on the back of the unit

using a #2 Philips

screwdriver.

4. Turn the lamp onto its

back. Remove the lens.

5. Check to see if a light

tube is loose. If loose,

remove and re-install.

6. Remove the elastic

around the metal clips.

7. Remove and discard the

rubber shipping insert at

the socket end of the

light tube.

8. To remove the light

tube, depress the white

clip in the middle of the

light housing unit (see

photo). With your other

hand, grasp the tube

near the plastic base

and gently wiggle it

until it rises above the

white clip.

9. Twist the light tube until

one side of the base

comes out of the socket.

10. The other side should

slide out with minimal

effort.

11. Now slide out or

disengage the light tube

from the retainer clip at

the other end.

Lens

Switch

Power Cord

Light Case Removable Legs

Height

Adjustment

Buttons

Knobs

3

Before Using Your Day-Light
