SAFETY INSTRUCTIONS (CONT.)

SAFETY! BEWARE OF SPIDERS

CAUTION: BURNERS MUST BE INSPECTED AND CLEANED BEFORE FIRST USE.

Spiders and small insects occasionally spin webs or make nests in the burners during warehousing, transit and/or after long periods of non-

use. These webs can lead to a gas flow obstruction, which could result in a fire in and around the burner tubes. This type of fire is known as

“FLASH-BACK” and can cause serious damage to your grill and create an unsafe operating condition for the user. Although an obstructed

burner tube is not the only cause of “FLASH BACK” it is the most common cause, and frequent inspection and cleaning of the burners is

necessary.

GENERAL SAFETY

-Keep outdoor cooking gas appliance area clear and free from combustible materials, gasoline and other flammable vapors and liquids.

-Do not obstruct the flow of ventilation.

-Keep the vent openings of the cylinder enclosure free and clear from debris.

-Visually check burner flame. Including pilot burner if provided.

-Clean outdoor cooking gas appliance with recommended cleaning agents.

-Check and clean burner/venturi tubes for insects and debris. A clogged tube can lead to a fire beneath the grill

NATURAL GAS SAFETY

Your Natural Gas (G20) grill is designed to operate on natural gas ONLY, at a pressure of 4” water column (W.C.)/10 mbar/.99 KPa regulated at

the natural gas regulator attached at the back of the grill. On CE versions, your Natural Gas (G20) grill is designed to operate on natural gas

ONLY, at a pressure of 5.8” water column (W.C.)/14.5 mbar/1.45 KPa regulated at the natural gas regulator attached at the back of the grill.

Check with your gas utility for local gas pressure and with your local municipality for building code requirements. In the United States, the natural

gas orifice size is 1.93mm. Outside the United States, the natural gas orifice size is 1.60mm.

Check with your gas utility or with local building codes for instructions to install gas supply line, or call a licensed and knowledgeable installer.

It is recommended that an “ON-OFF” shutoff valve be installed at the gas supply source:

- Outdoors after gas line piping exits outside wall or before gas line piping enters ground.

- Indoors in the branch fuel line in an accessible location near the supply line.

Do not use Teflon ® tape or pipe sealant on any flare ends because you will not obtain a leak-free seal.

Pipe sealing compound or pipe thread tape of the type resistant to the action of natural gas must be used on all male pipe thread. Apply

compound or tape to at least the first three threads when making the connection.

Disconnect your gas grill from fuel source when the gas supply is being tested at high pressures. This appliance and its individual shutoff valve

must be disconnected from the gas supply piping system during any pressure testing of that system at pressures in excess of 1/2 psig (3.5

KPa)/37 mbar.

Turn off your gas grill when the gas supply is being tested at low pressures. This appliance must be isolated from the gas supply piping system by

closing its individual valve.

WARNING: Gas valves are preset at the factory to operate on LP or natural gas. If you wish to convert to a different gas type, be sure to contact

your grill dealer, licensed plumber or authorized service center for further details. Conversion kits are not sold to the general public and require a

professional to perform service. Failure to properly convert a unit can cause serious injury to yourself and/or others, irreparable damage to your

grill and void of warranty.
