Bruksanvisning Bosch WTE84301GB Torktumlare

Bruksanvisning

1 2 3 4 5

6

Emptying condensation

Empty container after each drying operation!

1. Pull out condensation container keeping it horizontal.

2. Pour out condensation.

3. Always push container in fully until it clicks into place.

If Container flashes in the display panel a

What to do if..., Page 10.

Cleaning the fluff filter

Clean the fluff filter after each drying operation.

1. Open the door, remove fluff from door/door area.

2. Pull out and fold open the fluff filter.

3. Remove the fluff (by wiping the filter with your hand).

If the fluff filter is very dirty or blocked, rinse with warm water and dry

thoroughly.

4. Close and reinsert the fluff filter.

Switching off the dryer

Turn the programme selector to Off.

Do not leave laundry in the dryer.

Removing the laundry

The automatic anti-crease function causes the drum to move at specific intervals, the washing remains

loose and fluffy for an hour (two hours if the additional S

Reduced Ironing function is also selected-

depending on model).

... and adapt to individual requirements

Never start the dryer if it is damaged!

Inform your after-sales service.

Inspecting the

dryer

Sorting and loading laundry

Remove all items from pockets.

Check for cigarette lighters.

The drum must be empty prior to loading.

See programme overview on page 7.

See also separate instructions for “Woollens basket”

(depending on model)

Your new dryer

Congratulations - You have chosen a modern, high-quality Bosch

domestic appliance.

The condensation dryer is distinguished by its economical energy

consumption.

Every dryer which leaves our factory is carefully checked to ensure

that it functions correctly and is in perfect condition.

Should you have any questions, our after-sales service will be pleased

to help.

Disposal in an environmentally-responsible manner

Dispose of packaging in an environmentally-responsible manner.

This appliance is labelled in accordance with the European

guideline

2002/96/EG on waste electrical and electronic

equipment - WEEE.

The guideline provides an EU-wide framework for the return

and recycling of old appliances.

For further information about our products, accessories, spare parts

and services, please visit: www.bosch-home.com

Intended use

Preparing for

installation, see Page 8

Selecting and adjusting the programme

Drying

Condensation container

Control panel

ʋ for domestic use only,

ʋ only to be used for drying fabrics that have been

washed with water.

Do not leave children unsupervised near the dryer.

Keep pets away from the dryer.

The dryer can be operated by children 8 years old

and older, by persons with reduced physical,

sensory or mental abilities and by persons with

insufficient experience or knowledge if they are

supervised or have been instructed in its use by

a responsible adult.

Select the drying programme ...

Press the  Start/Stop button

1

2

3

Make sure your hands are dry.

Hold the plug only.

Connecting the

mains plug

Drying

Information on laundry ...

Labelling of fabrics

Follow the manufacturer's care information.

( Drying at normal temperature.

'cDrying at low temperature a also select & Low Heat.

)cDo not machine dry.

Observe safety instructions without fail a Page 11!

Do not tumble-dry the following fabrics for example:

– Impermeable fabrics (e.g. rubber-coated fabrics).

– Delicate materials (silk or curtains made from synthetic material) a they may crease

– Laundry contaminated with oil.

Drying tips

– To ensure a consistent result, sort the laundry by fabric type and drying programme.

– Always dry very small items (e.g. baby socks) together with large items of laundry

(e.g. hand towel).

– Close zips, hooks and eyelets, and button up covers.

Tie fabric belts, apron strings, etc. together

– Do not over-dry easy-care laundry a risk of creasing!

Allow laundry to finish drying in the air.

– Do not dry woolens in the dryer, only use to freshen them up a Page 7, Woollens finish

Programme (depending on model).

– Do not iron laundry immediately after drying, fold items up and leave for a while a

the remaining moisture will then be distributed evenly.

– The drying result depends on the type of water used during washing. a Fine adjustment

of the drying result a Page 5/6.

– Machine-knitted fabrics (e.g. T-shirts or jerseys) often shrink the first time they are dried a

do not use the Very Dry programme.

– Starched laundry is not always suitable for dryers a starch leaves behind a coating that

adversely affects the drying operation.

– Use the correct dosage of fabric softener as per the manufacturer's instructions when

washing the laundry to be dried.

– Use the timer programme for small loads a this improves the drying result.

Environmental protection / Energy-saving tips

– Before drying, spin the laundry thoroughly in the washing machine a the higher the spin

speed the shorter the drying time will be (consumes less energy), also spin easy-care

laundry.

– Put in, but do not exceed, the maximum recommended quantity of laundry a

programme overview a Page 7.

– Make sure the room is well ventilated during drying.

– Do not obstruct or seal up the air inlet.

– Keep the air cooler clean a Page 6 “Care and cleaning”.

Fine adjustment of the drying result

Adjustment of the levels of dryness

1 x to the right Press and hold & Low Heat

and turn 5 x to the right

Press & Low Heat until

the required level is reached

Turn to Off

Turn to Off

Drum

All buttons are sensitive and only

need to be touched lightly.

Only operate the dryer with

the fluff filter inserted!

Air inlet

Fluff filter

Drum interior light

(depending on model)

Maintenance

flap

Programme end once lights up in the display.

Interrupt programme removing or adding laundry.

The drying cycle can be interrupted for a brief period so that laundry may be added or removed.

The programme selected must then be resumed and completed.

Never switch the dryer off before the drying process has ended.

Drum and door may be hot!

1. Open door, the drying process is interrupted.

2. Load or remove laundry and close door.

3. If required, select a new programme and additional functions.

4. Press the  Start/Stop button.

Additional

functions

Programme selector

Display panel

Service

indicators

Container

Filter

Empty the condensation container.

Clean the fluff filter and/or air cooler under running water. a Page 4/6.

Select On/Off for buzzer at the end of the programme. ˎ & Buzzer

Reduced temperature for delicate fabrics ' that require a longer

drying time; e.g. for polyacrylics, polyamide, elastane or acetate.

ˎ & Low Heat

Reduces creasing and extends the anti-creasing phase once the

program has ended.

ˎ S Reduced

Ironing

Read these instructions and the separate

Energy-saving mode instructions before

operating the dryer.

Observe the safety instructions on page 11.

Contents Page

ʋ Preparation . . . . . . . . . . . . . . . . . . . . . . 2

ʋ Setting the programmes . . . . . . . . . . . . . 2

ʋ Drying . . . . . . . . . . . . . . . . . . . . . . . . 3/4

ʋ Information on laundry . . . . . . . . . . . . . . 5

ʋ Fine adjustment of the drying result . . 5/6

ʋ Care and cleaning . . . . . . . . . . . . . . . . . 6

ʋ Programme overview . . . . . . . . . . . . . . . . 7

ʋ Installation . . . . . . . . . . . . . . . . . . . . . . . . 8

ʋ Frost protection / Transport . . . . . . . . . . . 8

ʋ Technical data . . . . . . . . . . . . . . . . . . . . 9

ʋ Optional accessories . . . . . . . . . . . . . . . . 9

ʋ What to do if... / After-sales service . . . . 10

ʋ Safety instructions . . . . . . . . . . . . . . . . 11

ˎ h:min  End of programme in 1*-24 hours (Press button several times if required)

(*depending on the selected programme, e.g. duration 1:54h a 2h.

Can always be selected to the next full hour.)

Fine

adjustment

of the drying

result

The drying result (e.g. Cupboard Dry) can be adjusted over three levels (1 - max. 3)

for the L

Cottons, I Easy-Care, / Mixed Load and  Super Quick 40’ programmes a

presetting = 0. After one of these programmes has been finely adjusted, the setting is

retained for the others. Further information aPage 5/6.

0, 1, 2, 3

Time

remaining

Fine adjustment of the drying result

Care and cleaning

Dryer housing, control panel, air cooler, moisture sensors

– Wipe with a soft, damp cloth.

– Do not use harsh cleaning agents and solvents.

– Remove detergent and cleaning agent residue immediately.

Clean the protective filter 5 - 6 times a year

or if Filter flashes after cleaning the fluff filter.

Air cooler / Protective filter

When cleaning, only remove the protective filter. Clean the air cooler

behind the protective filter once a year.

– Allow the dryer to cool.

– Residual water may leak out, so place an absorbent towel

underneath the maintenance door.

1. Unlock the maintenance door.

2. Open the maintenance door fully.

3. Turn both locking levers towards each another.

4. Pull out the protective filter/air cooler.

Do not damage the protective filter or air cooler.

Clean with warm water only. Do not use any hard or sharp-edged

objects.

5. Clean the protective filter/air cooler thoroughly,

Allow to drip dry.

6.

Clean the seals.

7. Re-insert the protective filter/air cooler,

with the handle facing down.

8. Turn back both locking levers.

9. Close the maintenance door until the lock clicks into place.

Moisture sensors

The dryer is fitted with stainless steel moisture sensors. The sensors

measure the level of moisture in the laundry. After a long period of

operation, a fine layer of limescale may form on the sensors.

1. Open the door and clean the moisture sensors with a damp sponge

which has a rough surface.

Do not use steel wool or abrasive materials.

L:00, L:01, L:02, L:03 are shown in sequence

Short signal when changing from L:03 to L:00, otherwise long

signal.

Only when switched off!
