8
Care and cleaning
Dryer housing, control panel
– Wipe clean with a soft, damp cloth.
– Do not clean with a water jet.
– Remove detergent and cleaning agent residue immediately.
– During drying, water may occasionally accumulate between the window and the seal.
This does not affect the proper operation of your dryer.
Heat exchanger
The heat exchanger requires cleaning once a month, however this varies depending on
how frequently the dryzer is used.
Allow the dryer to cool down and place an absorbent cloth under the maintenance flap.
Residual water may escape.
1. Unlock the maintenance flap and open completely.
2. Turn both locking levers towards each another.
3. Pull out the cap.
4. Remove the heat exchanger.
Take care not to damage the heat exchanger.
When cleaning, use water only. Do not use hard or sharp-edged objects.
5. Rinse the heat exchanger and the cap on all sides with a jet of water to
completely remove all of the fluff.
6. Remove any fluff from the seals on the dryer and heat exchanger.
7. Allow to drip dry fully.
8. First insert the heat exchanger, then the cap.
9.
Turn back both locking levers and close the
maintenance flap until it locks closed.
Moisture sensors
The dryer is equipped with stainless steel moisture sensors.
Moisture sensors measure the moisture level of the laundry.
After sustained, repeated operation, a fine layer of limescale
may form on the moisture sensors.
1. Open the door.
2. Clean the moisture sensors with a damp sponge which has a rough
surface.
Do not use steel wool or abrasive agents!
Only when switched off!
9
Installation
– Scope of delivery: dryer, operating and installation instructions, basket for woollens
(depending on the model).
– Check the dryer for transport damage.
– The dryer is very heavy. Do not attempt to lift it on your own.
– Be careful to avoid sharp edges.
– Do not lift the dryer by protruding parts (e.g. the door) - risk of breakage.
– Do not set up in a room that is susceptible to frost.
Freezing water may cause damage.
– If in doubt, have the appliance connected by a specialist.
Setting up the dryer
– The mains plug must always be accessible.
– Ensure that the appliance is placed on a clean, level and
firm surface.
– Do not obstruct the air inlet on the dryer.
– Keep the area around the dryer clean.
– Level the dryer using the threaded feet
and a spirit level.
Never remove the threaded feet!
For mains connection, see Safety instructions a page 13.
– Connect to an AC earthed socket. If in doubt have the socket checked by a specialist.
– The mains voltage and the voltage shown on the rating plate (a page 10) must be the same.
– The connected load and necessary fuse protection are specified on the rating plate.
Frost protection / Transport
Preparation
1. Empty the condensate container a page 4/11.
2. Select any programme using the programme selector.
3. Press the $ Start/Reload button a condensation is pumped into the container.
4. Wait several minutes or until the dryer stops, and then empty the condensate container
again.
5. Turn the programme selector to Off.
1.
Take all accessory parts out
of the drum.
The drum must be empty.
Make sure that the air inlet
remains unobstructed
Clean and level
Do not install the dryer behind a door
or sliding door which could prevent or
obstruct the dryer door from opening.
This will prevent children from locking
themselves in and risking their lives.
2.
Do not operate the dryer if
there is a risk of frost.
10
Technical Data
ʠ
Dimensions (DxWxH) 60 x 60 x 85 cm (height adjustable)
Weight approx. 45 kg
Max. capacity 9 kg
Condensate container 4.2 l
Connection voltage 220-240 V
Connected load 2600 W
Fuse protection 13 A
Ambient temperature 5-35°C
Product number
Production number
Inside of door
The rating plate can be found on the back of the dryer.
Power consumption when switched off 0.10 W
Power consumption when ready for use (left-on mode) 0.50 W
ʠ
Drum interior light (depending on model): The drum lights up after the door is opened and after the
programme starts, and switches off automatically.
Consumption values table
Programme
Spin speed which
is used for spinning
the laundry
Duration** Energy consumption**
LCottons 9 kg 4.5 kg 9 kg 4.5 kg
+. Cupboard dry* 1400 rpm 129 min 69 min 4.36kWh 2.32 kWh
1000 rpm 150 min 80 min 5.23 kWh 2.78 kWh
800 rpm 171 min 91 min 6.02 kWh 3.20 kWh
|üIron dry* 1400 rpm 102 min 54 min 2.61 kWh 1.39 kWh
1000 rpm 123 min 66 min 4.01 kWh 2.13 kWh
800 rpm 144 min 77 min 4.50 kWh 2.39 kWh
I÷Easy-Care 3.5 kg 3.5 kg
+. Cupboard dry* 800 rpm 46 min 1.42 kWh
600 rpm 56 min 1.74 kWh
For testing in accordance with applicable standard EN61121 the dryer shall be used with external drain set.
* Programme setting for testing in accordance with the applicable EN61121 standard.
** The values may differ from those specified, depending on the type of fabric, composition of laundry to be dried, residual moisture in the fabric
and the amount of laundry being loaded.
Most efficient programme for cotton fabrics
The following "standard cottons programme" (identified with ) is suitable for drying normal, wet cotton laundry and is most efficient in terms of
its combined energy consumption for drying wet cotton laundry.
Standard programme for cottons in accordance with current EU regulation 932/2012
Programme Load Energy consumption Programme duration
Cottons Cupboard dry 9 kg/4.5 kg 5.23 kWh/2.78 kWh 150 min/80 min
Programme setting for testing and energy labelling in accordance with Directive 2010/30/EU.
Optional accessories (order from the after-sales service using the order number, depending on the model)
Washer-dryer stack connection set
The dryer can be placed on top of a suitable washing machine with the same width and depth to save space.
The dryer must be fastened to the washing machine using this connection set.
WTZ 11400: with pull-out worktop.
Platform
For easier loading and unloading. The basket contained in the drawer can be used to carry the laundry.
WTZ
20410
WTZ
20500
11
What to do if ...
Turn the programme selector to Off and remove the mains plug from the socket.
ʠ
The $ Start/Reload indicator
light does not light up.
Mains plug plugged in?
Programme selected?
Check the socket fuse.
ʠ
The display panel light
and indicator lights (depending
on model) go out
and the $ Start/Reloadindicator
light flashes.
Energy-saving mode is activated a see the separate
Energy-saving mode instructions.
ʠ
The display panel switches off. The appliance goes into the sleep mode after activating
Finished in option apage 5.
ʠ
The Í (Condensate container)
indicator light flashes.
Empty the condensate container apage 4.
Press the $ Start/Reload button to reset the displayed
indication and then press the $ Start/Reload button
again to restart the appliance if necessary.
If featured, check the hose for condensation outlet.
ʠ
p(Fluff filter/Heat exchanger)
indicator light flashes.
Clean the fluff filter a page 4.
Press the $ Start/Reload button to reset the displayed
indication and then press the $ Start/Reload button
again to restart the appliance if necessary.
Clean the heat exchanger a page 8.
ʠ
Dryer does not start. $ Start/Reload button selected?
Door closed?
Programme set?
After-sales service
If you cannot rectify the fault yourself (e.g. switching off/on) a What to do if..., page 11/12,
please contact our after-sales service. We will always find an appropriate solution and avoid
unnecessary visits by engineers.
The contact details of your local after-sales service can be found in the enclosed after-sales
service directory.
– GB 0344 892 8979 (Calls charged at local or mobile rate.)
– IE 01450 2655 (0.03 € per minute at peak. Off peak 0.0088 € per minute.)
Please provide the after-sales service the product number (E no.) and the production number
(FD) of the appliance.
Product number Production number
You can find this information:
inside the door* / in the opened service flap*
and on the rear of the appliance.
*depending on the model
Trust the expertise of the manufacturer. Contact us for assistance. In this way, you can rest
assured that the repair will be carried out by trained service technicians using original spare
parts.
12
What to do if ...
ʠ
Programme terminates shortly
after starting.
Ambient temperature greater than 5°C?
Is the appliance loaded with the laundry?
Load too small for selected programme?/Use timed
programme apage 6/7.
Loaded laundry dry?
ʠ
Water is leaking out. Make sure the dryer is level.
Clean the heat exchanger seal.
ʠ
The door opens by itself. Push the door closed until you hear it engage.
ʠ
Creasing. Laundry load exceeded?
Remove articles of clothing immediately after the end
of the programme, hang up and pull into shape.
Unsuitable programme selected a page 7.
ʠ
Laundry is not dried correctly or is
still too damp.
After the end of the programme, warm laundry feels
damper than it actually is. Spread the laundry out and
allow the heat to disperse.
Finely adjust the dryness level – this extends the drying
time but does not increase the temperature. Your laundry
will become drier.
Select a programme with a longer drying time or increase
the drying level. This does not increase the temperature.
Select a time programme for extended drying of laundry
that is still damp.
If you have exceeded the maximum load for the
programme, the laundry may not be dried correctly.
Clean the moisture sensor in the drum. A fine layer of
limescale may adversely affect the performance of the
sensors and your washing will not dry properly.
Drying has been interrupted as a result of a power cut,
because the condensate container is full or because the
maximum drying time has been exceeded.
ʠ
Drying time too long. Clean the fluff filter under running water a page 4/11.
Insufficient supply of air a Ensure that air can circulate.
Air inlet possibly blocked a Clear inlet a page 9.
Ambient temperature higher than 35°C a Ventilate the
room.
ʠ
One or more indicator lights are
flashing.
Clean the fluff filter and heat exchanger a page 4,8/11.
Check the installation conditions a page 9.
Switch off, allow to cool, switch back on and restart the
programme.
ʠ
Power failure. Remove the laundry from the dryer immediately and
spread out. This allows the heat to dissipate. Be careful
as the door, the drum and the laundry may be hot.
13
Safety instructions
Emergency – Pull the appliance plug out of the socket immediately or disconnect the fuse.
ONLY use
the dryer...
– in rooms inside the house.
– to dry fabrics.
The dryer
must NEVER...
– be used for purposes other than those described above.
– be modified in terms of its technology or properties.
Hazards – The dryer must not be used by children or persons who have not been instructed in
its use.
– Do not leave children unsupervised near the dryer.
– Keep pets away from the dryer.
– Remove all objects from pockets, and lighters in particular a Risk of explosion!
– Do not lean or sit on the door a Risk of tipping!
Installation – Secure loose cables a Risk of tripping!
– Do not operate a dryer if there is a risk of frost.
Mains
connection
– Connect the dryer to an AC earthed socket according to specifications, otherwise it
cannot be guaranteed that the appliance is completely safe.
– The cable cross-section must be sufficient.
– Only use earth-leakage circuit breakers with the following symbol:
– The appliance plug and socket must be compatible.
– Do not use multiple plugs/connectors and/or extension cables.
– Do not touch or hold the appliance plug with wet hands a Risk of electric shock!
– Never pull the appliance plug out of the socket by its cable.
– Do not damage the mains lead a Risk of electric shock!
Operation – Only load the drum with laundry.
Check the contents before you switch the dryer on.
– Do not use the dryer if the laundry has been in contact with solvents, oil, wax, grease
or paint (e.g. hair setting spray, nail polish remover, stain remover, cleaning solvent,
etc.) a fire/explosion hazard.
– The tumble dryer is not to be used if industrial chemicals have been used for
cleaning.
– Dust (e.g. coal dust, flour) poses a danger: do not use the dryer aexplosion
hazard.
– Do not turn off the dryer until the drying process ends, unless the laundry will be
removed quickly and spread out, so that the heat can dissipate.
– Do not put laundry containing foamed material/rubber in the dryer a elastic
material may be destroyed and the dryer may be damaged due to possible
deformation of the foamed material.
– When cleaning the fluff filter, make sure that no foreign material (down or filling
material) gets into the air duct opening. If necessary, clean the drum beforehand
with a vacuum cleaner. If foreign material should still get into the air duct a call the
after-sales service a Risk of fire/explosion.
– Light things, such as long hair, may be sucked into the air inlet of the dryer aRisk
of injury.
– Final part of a tumble dryer cycle occurs without heat (cool down cycle), to ensure
that the items are left at a temperature that ensures that the items will not be
damaged.
– Switch off the dryer once the programme has ended.
– The exterior of the appliance's rear panel becomes very hot during
operation. Never touch the hot surface of the appliance's rear panel. Keep
children away from the appliance a Risk of burns!
– The water from condensation is not drinking water and may be
contaminated with fluff.
Defect – Do not use the dryer if it is defective or if you suspect that it is.
Repairs must only be carried out by the after-sales service.
– Do not use the dryer if the mains cable is defective. To avoid danger, only have the
defective mains cable replaced by the after-sales service.
Spare parts – For safety reasons, you must only use genuine spare parts and accessories.
Disposal – Pull out the appliance plug, then cut off the mains cable from the appliance.
Dispose of the appliance at a municipal waste disposal site.
– Packaging: Keep all packaging out of reach of babies and children
a Risk of suffocation!
– All materials are environmentally sound and can be reused.
Dispose of them in an environmentally-responsible manner.
en Instruction manual
Dryer
WTB86590GB
Ladda ner bruksanvisning i Engelska (PDF, 4.71 MB)
(Tänk på miljön och skriv endast ut denna bruksanvisning om det verkligen är nödvändigt)
Loading…
Betyg
Berätta vad du tycker om Bosch WTB86590GB Torktumlare genom att betygsätta den. Vill du dela med dig av dina åsikter om denna produkt eller ställa en fråga? Lämna en kommentar nederst på sidan.Mer om denna bruksanvisning
Vi förstår att det är trevligt att ha en pappersbruksanvisning för din Bosch WTB86590GB Torktumlare. Du kan alltid ladda ner bruksanvisningen från vår hemsida och skriva ut den själv. Om du vill ha en originalbruksanvisning rekommenderar vi att du kontaktar Bosch. De kanske kan tillhandahålla en originalbruksanvisning. Letar du efter bruksanvisningen för din Bosch WTB86590GB Torktumlare på ett annat språk? Välj ditt föredragna språk på vår hemsida och sök efter modellnumret för att se om vi har det tillgängligt.
Specifikationer
| Märke | Bosch |
| Modell | WTB86590GB |
| Kategori | Torktumlare |
| Filtyp | |
| Filstorlek | 4.71 MB |
Alla bruksanvisningar för Bosch Torktumlare
Fler bruksanvisningar för Torktumlare
Vanliga frågor om Bosch WTB86590GB Torktumlare
Vårt supportteam söker efter användbar produktinformation och svar på vanliga frågor. Om du hittar en felaktighet bland våra vanliga frågor uppskattar vi om du meddelar oss detta via vårt kontaktformulär.
Varför är trumman i min torktumlare större än min tvättmaskin, trots att de har samma kapacitet? Verifierad
För att torka ordentligt, måste en torktumlare ha luft. Detta kräver utrymme och det är därför trumman behöver vara större.
Detta hjälpte (3211) Läs merVad är skillnaden mellan en kondenstorktumlare och frånluftstorktumlare? Verifierad
I en kondenstorktumlare rinner den kondenserade vattenångan ned i en invändig behållare. I en frånluftstorktumlare dräneras den heta, fuktiga luften genom en slang, till exempel ut genom ett fönster. En frånluftstorktumlare är billigare att använda än en kondensortorktumlare.
Detta hjälpte (1110) Läs merKan jag ställa min tvättmaskin och torktumlare ovanpå varandra? Verifierad
I princip går det bra att stapla en torktumlare och tvättmaskin. Det fungerar förstås bara med frontladdade modeller. Vi rekommenderar att använda ett speciellt monteringstillbehör. Det förhindrar att maskinerna vibrerar och ramlar ned samt förhindrar skador på den undre maskinen.
Detta hjälpte (858) Läs merKan jag ansluta en torktumlare till en förlängningssladd? Verifierad
Enheter som kräver stora mängder ström, som en torktumlare, kan inte anslutas till alla förlängningssladdar. Se vad torktumlaren använder, vilket anges i Watt, och kontrollera om förlängningssladden klarar det. Det finns förlängningssladdar med tjockare kablar som är gjorda för att hantera större apparater.
Detta hjälpte (690) Läs merVad är skillnaden i användning mellan en tvättmaskin och en separat tvättmaskin och torktumlare? Verifierad
Den största fördelen med en tvättmaskin är att den tar mindre plats. En separat torktumlare kan dock torka mer än en tvättmaskin. En tvättmaskin använder också relativt mer energi och kräver mer tid.
Detta hjälpte (686) Läs mer
Delta i konversationen om denna produkt
Här kan du dela vad du tycker om Bosch WTB86590GB Torktumlare. Om du har en fråga, läs först noggrant igenom manualen. Att begära en manual kan göras genom att använda vårt kontaktformulär.
