1 2 3 4 5 6
]7 - 90 °C V (Temperature) Select the temperature (7]= cold)
1 - 24h (Finished in) Programme end after
cc- 1400*
c(rpm)
Select the spin speed (* model-dependent) or (Rinse hold
= no final spin, laundry remains in the water after the final rinse,
--- appears in the display panel).
Status indicators Programme status indicators:
1üü2üücü- ¯- Wash, rinse, spin, programme duration or end (- ¯-)
(
Childlock apage 5
, Open the washing machine door, add laundry apage 4, 5
Programme selector
Display panel /
Options buttons
Start/
Reload
Additional
functions
Sort and load the laundry
Follow the manufacturer's care information.
According to the information on the care labels.
According to type, colour, level of soiling and temperature.
Do not exceed the maximum load a page 7.
Observe the important information a page 9.
Insert items of laundry of varying sizes.
Close the washing machine door. Take care not to trap items of laundry between the washing
machine door and the rubber seal.
Add detergent and care product
Measure according to:
The amount of laundry, level of soiling, water hardness (ask your water supply company) and
manufacturer's instructions.
On models without an insert for liquid detergent:
Pour liquid detergent into the appropriate dispenser and place in the drum.
During operation, open the detergent drawer with care.
Individual settings
ʑ
Signal
ʑ
$ Start/Reload
To start the programme or to subsequently load additional laundry, and to activate/deactivate the childlock.
1. Activate the
setting mode for
signal volume
Set to •
1 step, the
display panel
lights up
Press and
hold
+
1 step,
release
Set to •
Button signals
Information signals
Set the
volume*
1 step
Set the
volume*
* you may need to select the function several times
2. Set the
volume for ...
skip
Insert for liquid detergent (depending on model), page 10
Compartment II: detergent for main wash,
Water softener, bleach, stain remover
Your washing machine Intended use
Contents Page
ʔ Intended use .......................................................................................................................... 1
ʔ Programmes .......................................................................................................................... 1
ʔ Setting and adjusting the programme ............................................................................. 3
ʔ Washing ..............................................................................................................................3/4
ʔ After washing ........................................................................................................................ 4
ʔ Individual settings ............................................................................................................5/6
ʔ Overview of programmes ................................................................................................... 7
ʔ Safety instructions ................................................................................................................ 8
ʔ Consumption values ............................................................................................................8
ʔ Important information .........................................................................................................9
ʔ Insert for liquid detergent ................................................................................................ 10
ʔ Care ...................................................................................................................................... 10
ʔ Information on the display panel ................................................................................... 10
ʔ Instructions for blockages ............................................................................................... 11
ʔ What to do if.................................................................................................................. 12/13
ʔ Emergency release ............................................................................................................ 13
ʔ After-sales service.............................................................................................................. 13
Environmental/savings tips
– Always fill the washing machine with a maximum amount of laundry for
the relevant programme.
– Wash normally soiled laundry without a prewash.
– The selectable temperatures apply to the care labels on the textiles. The
temperatures in the machine may deviate from this so that you get the optimum mix
of energy-saving and washing results.
– Measure the detergent according to the manufacturer's instructions and water
hardness.
– If you want to dry the laundry in the tumble dryer afterwards, select a spin speed
suggested by the dryer manufacturer.
Preparation
Before washing for the first time
Run a wash cycle without any laundry a page 9
Set** and adjust the programme
1
2
Washing
Compartment ~: fabric softener, starch
Compartment I: detergent for prewash
ʔ For domestic use only
ʔ For washing machine-washable fabrics and hand-washable wool in
detergent solution
ʋ To be operated with cold drinking water and commercially available
detergents and care products which are suitable for use in washing
machines.
– Do not leave children unattended near the washing machine.
– The washing machine is not to be used by children or persons
not familiar with the operating instructions.
– Keep pets away from the washing machine.
Dilute thick fabric softener and conditioner with water.
This prevents blockages.
Detergent drawer
with compartments I, II, ~
Control panel
Washing machine
door handle
Service flap
Washing machine door
Correct installation according to the separate
Installation instructions.
Check the machine
– Never use a damaged machine.
– Inform the after-sales service.
Connect the mains plug
– Make sure your hands are dry.
– Take hold of the plug only.
Turn the tap on
**If the ( symbol is lit in the display
panel, the childlock is active
aDeactivate it, page 5.
Additional functions and options buttons
aIndividual settings, page 5
Press $ Start/Reload
Washing
End of programme when ...
... the $ Start/Reload button is off and - ¯- appears in the
display panel.
If the display panel lighting is off, press any button
a Energy-saving mode, page 5.
Cancel the programme
Programmes at high temperatures:
– To cool the laundry: Select Rinse .
– Press $ Start/Reload.
Programmes at lower temperatures:
– Select Spin or Drain >.
– Press $ Start/Reload.
Change the programme if...
... you have selected the wrong programme by mistake:
– Reselect the preogramme.
– Press $ Start/Reload. The new programme starts from the
beginning.
Add laundry when ... a page 5
... $ Start/Reload is pressed and in the display panel both §+ ,
symbols are then lit.
If ǯ is lit, the washing machine door cannot be opened.
Select the $ Start/Reload button.
Individual settings
ʑ
Options buttons
The spin speed and temperature can be changed before and during the selected programme. The effects depend on
the programme progress.
ʑ
V (Temperature °C)
You can change the displayed washing temperature. The maximum washing temperature that can be selected depends
on the programme that has been set.
ʑ
(Finished in)
When you select the programme, the relevant programme duration is displayed. You can delay the start of the programme
before it begins. The "Finished in" time can be set in increments of one hour up to a maximum of 24 hours. Press the
(Finished in) button repeatedly until the desired number of hours is displayed (h = hour). Press $ Start/Reload.
ʑ
(Spin speed in rpm) / (Rinse hold = no final spin)
You can change the spin speed shown or select c(Rinse hold = no final spin, laundry remains in the water after the
final rinse, --- appears in the display panel). You can change the spin speed shown. The maximum selectable spin
speed depends on the model and on which programme is currently selected.
ʑ
Additional functions a and overview of programmes, page 7
Ĉ Speed Perfect
For washing in a shorter time with a washing result comparable to that of the standard pro-
gramme. Maximum load a Overview of programmes, page 7.
ć Eco Perfect
Energy-optimised washing by reducing the temperature while achieving a consistent washing
result. The washing temperature is lower than the selected temperature. For special hygiene
requirements, the Allergy+ ā÷programme is recommended.
S
Reduced Ironing
Special spin sequence with subsequent fluffing. Gentle final spin at reduced speed.
Residual moisture in the laundry is increased slightly.
= Aqua Plus
Additional rinse cycle. Increased water level. For areas with very soft water or for further
improving the washing result.
ʑ
Childlock
(
in the display panel
You can lock the washing machine to prevent the functions you have set from being changed
inadvertently.
ON/OFF: after the start/end of the programme, press and hold $ Start/Reload for approx.
5 seconds.
Note: The childlock can remain activated until you wish to start the next programme, even after
switching off the machine.
Then you can deactivate the childlock before starting the programme and activate it again as
necessary once the programme has started.
Note:
– The (symbol is lit: Childlock active.
– The (symbol flashes: Childlock active and then the programme selector is altered.
To prevent the programme from stopping, turn the programme selector back to the original
programme, the ( symbol is lit again.
ʑ
Add laundry
§ + o,
in the display panel
If you want to add additional items of laundry after the programme has started, press the
$ Start/Reload button. The machine checks whether adding laundry is possible.
§ + , are lit: Adding laundry is possible.
ǯ
flashing: Wait until § + , are lit.
Note: Only open the washing machine door when both the § + , symbols are lit.
ǯ: It is not possible to add laundry.
Note: for safety reasons, the washing machine door remains locked when the water level and/or
temperature is high, or during spinning.
To continue the programme, press the $
Start/Reload button.
ʑ
Energy saving mode
If the washing machine is switched on and is not operated for several minutes before the programme starts or at the end of the
programme, the display panel light goes out and the $ Start/Reload button flashes.
Press any button to turn the light back on.
Programme selector for switching the
machine on and off and for selecting
the programme. Can be turned in
either direction.
All buttons are sensitive and need only
to be touched lightly. If you press and
hold the (Finished in) option button,
the appliance automatically runs
through the settings options.
3
Programmes
Detailed overview of programmes a page 7.
Temperature and spin speed can be selected individually,
depending on the selected programme and programme progress.
Cottons L Hard-wearing fabrics
+ Prewash Hard-wearing fabrics, prewash at 30 °C
Easy-Care I Easy-care fabrics
+ Prewash Easy-care fabrics, prewash at 30 °C
Mixed Load /
Different types of laundry
Delicate/Silk Delicate washable fabrics
Wool : Hand/machine-washable wool
Rinse Extra rinse with spin
Spin Extra spin with selectable spin speed
Drain > the rinsing water when c
(Rinse hold = no final spin)
Gentle Spin Extra spin with reduced spin speed
SuperQuick 15' 6 Super Quick programme
Allergy+ ā Especially suitable for increased hygienic
demands or particularly sensitive skin on account
of prolonged washing at a defined temperature,
with a higher water level and longer rinsing cycle
Sportswear $ Fabrics made from microfibre
Dark Wash K Dark-coloured fabrics
Switch off
Turn the programme selector to Off.
Turn off the tap
Not required for AquaStop models
a Refer to Installation instructions.
Remove the laundry
Open the washing machine door and remove the laundry.
If (Rinse hold = no final spin) is active: turn the programme selector
to Drain > or Spin . Select the spin speed if necessary.
Press $ Start/Reload.
– Remove any foreign objects - risk of rusting.
– Leave the washing machine door and detergent drawer open
so that any residual water can dry away.
Congratulations - you have chosen a modern, high-quality domestic appliance
manufactured by Bosch. This washing machine is distinguished by its economical water
and energy consumption.
Each machine that leaves our factory has been inspected thoroughly to ensure that it
functions properly and is in perfect condition.
For more information on our products, accessories, replacement parts and services, visit
our website www.bosch-home.com or contact one of our after-sales service centres.
7
Overview of programmes a Check the consumption values table on page 8 and the instructions on page 9.
* reduced load for additional Ĉ Speed Perfect function.
As a short programme, Mixed Load /÷40 °C is ideal, when maximum spin speed is selected.
Programmes without prewash - add detergent to compartment II, programmes with prewash - distribute the detergent between compartments I and II.
Programmes °C max.
Type of laundry
Additional functions; options; information
Cottons L
7 - 90 °C
9 kg/
5 kg*
Hard-wearing fabrics, heat-resistant fabrics
made of cotton or linen
Ĉ Speed Perfect*, ć Eco Perfect, S Reduced Ironing,
= Aqua Plus, c(Rinse hold)
+ Prewash
Allergy+ ā 7 - 60 °C
8 kg/
5 kg*
Hard-wearing fabrics made of cotton or linen
Ĉ Speed Perfect*, ć Eco Perfect, S Reduced Ironing,
= Aqua Plus, c(Rinse hold); Especially suitable for increased hygienic
demands or particularly sensitive skin on account of prolonged washing at a
defined temperature, with a higher water level and longer rinsing cycle
Easy-Care I
7 - 60 °C 4 kg
Easy-care fabrics made of cotton, linen,
synthetic fibres or blended fabrics
Ĉ Speed Perfect, ć Eco Perfect, S Reduced Ironing, = Aqua
Plus, c(Rinse hold)
+ Prewash
Mixed Load /
7 - 40 °C
3,5 kg
Fabrics made of cotton or easy-care fabrics
ĈSpeed Perfect, ć Eco Perfect, S Reduced Ironing, = Aqua Plus,
c(Rinse hold); different types of laundry can be washed together
Dark Wash K 7 - 40 °C
Dark-coloured fabrics made of cotton and dark
easy-care fabrics
ĈSpeed Perfect, ć Eco Perfect, SReduced Ironing, = Aqua Plus,
c(Rinse hold); reduced rinse and final spin
Delicate/Silk 7 - 40 °C
2 kg
For delicate, washable fabrics, e.g. made of silk,
satin, synthetic fibres or blended fabrics
(e.g. curtains)
ĈSpeed Perfect, ć Eco Perfect, SReduced Ironing, = Aqua Plus,
c(Rinse hold); no spin between the rinse cycles
Wool : 7 - 40 °C
Hand or machine-washable fabrics made of
wool or containing wool
c(Rinse hold); Particularly gentle wash programme to prevent shrinkage of
laundry. Longer programme pauses (fabrics rest in the detergent solution)
SuperQuick 15' 6 7 - 40 °C
Easy-care fabrics made of cotton, linen,
synthetic fibres or blended fabrics
c(Rinse hold); Short programme, approx. 15 minutes, suitable for lightly
soiled laundry
Sportswear $ 7 - 40 °C Fabrics made from microfibre
Ĉ Speed Perfect, ć Eco Perfect, S Reduced Ironing, = Aqua Plus,
c(Rinse hold); Do not treat laundry with fabric softener
Additional programmes Rinse , Spin , Drain >, Gentle Spin
9406/ 9001015618
*1015618*
WAS32462GB
Robert Bosch Hausgeräte GmbH
Carl-Wery-Str. 34
81739 München / Deutschland
Delta i konversationen om denna produkt
Här kan du dela vad du tycker om Bosch WAS32462GB Tvättmaskin. Om du har en fråga, läs först noggrant igenom manualen. Att begära en manual kan göras genom att använda vårt kontaktformulär.
