English | 9

Bosch Power Tools 1 609 92A 35R | (6.6.16)

GSB 14,4 VE-EC / GSB 18 VE-EC

Typically the A-weighted noise levels of the product are: Sound pressure level 87 dB(A); Sound power level 98 dB(A). Uncer-

tainty K =3 dB.

Wear hearing protection!

The vibration level given in this information sheet has been

measured in accordance with a standardised test given in

EN 60745 and may be used to compare one tool with anoth-

er. It may be used for a preliminary assessment of exposure.

The declared vibration emission level represents the main ap-

plications of the tool. However if the tool is used for different

applications, with different accessories or insertion tools or is

poorly maintained, the vibration emission may differ. This

may significantly increase the exposure level over the total

working period.

An estimation of the level of exposure to vibration should also

take into account the times when the tool is switched off or

when it is running but not actually doing the job. This may sig-

nificantly reduce the exposure level over the total working

period.

Identify additional safety measures to protect the operator

from the effects of vibration such as: maintain the tool and the

accessories, keep the hands warm, organisation of work pat-

terns.

Assembly

Battery Charging

Note: The battery supplied is partially charged. To ensure full

capacity of the battery, completely charge the battery in the

battery charger before using your power tool for the first time.

The lithium-ion battery can be charged at any time without re-

ducing its service life. Interrupting the charging procedure

does not damage the battery.

The lithium-ion battery is protected against deep discharging

by the “Electronic Cell Protection (ECP)”. When the battery is

empty, the machine is switched off by means of a protective

circuit: The inserted tool no longer rotates.

 Do not continue to press the On/Off switch after the

machine has been automatically switched off. The bat-

tery can be damaged.

Removing the battery

The battery 12 is equipped with two locking levels that should

prevent the battery from falling out when pushing the battery

unlocking button 13 unintentionally. As long as the battery is

inserted in the power tool, it is held in position by means of a

spring.

To remove the battery 12, press the unlocking button 13 and

pull out the battery toward the front. Do not exert any force.

Auxiliary Handle

 Operate your machine only with the auxiliary handle 4.

 Before performing any work, make sure that the auxil-

iary handle is firmly tightened. Loss of control can lead

to injury.

Mounting the Auxiliary Handle

To open the auxiliary handle, turn the bottom part of the aux-

iliary handle 4 in counterclockwise direction.

Pull back the intermediate piece of the auxiliary handle 5 and

hold it in this position. Slide the auxiliary handle over the drill

chuck to mount the auxiliary handle on the power tool. Then

let go of the intermediate piece 5.

Afterwards, tighten the bottom part of the auxiliary handle 4

again by turning in clockwise direction.

Changing the position of the auxiliary handle

The auxiliary handle 4 can be set to any position for a secure

and low-fatigue working posture.

Turn the bottom part of the auxiliary handle 4 in counterclock-

wise direction and swivel the auxiliary handle 4 to the desired

position. Then retighten the bottom part of the auxiliary han-

dle 4 by turning in clockwise direction.

GSR 14,4 VE-EC GSR 18 VE-EC GSB 14,4 VE-EC GSB 18 VE-EC

Vibration total values a

h

(triax vector sum)

and uncertainty K determined according to

EN 60745-2-1, EN 60745-2-2.

Drilling in metal:

a

h

K

Impact drilling in concrete:

a

h

K

Screws:

a

h

K

m/s

2

m/s

2

m/s

2

m/s

2

m/s

2

m/s

2

2.5

1.5

-

-

< 2.5

1.5

2.5

1.5

-

-

< 2.5

1.5

2.5

1.5

12,5

1,5

< 2.5

1.5

2.5

1.5

12,5

1,5

< 2.5

1.5

OBJ_BUCH-2699-002.book Page 9 Monday, June 6, 2016 2:08 PM
