English | 5

Bosch Power Tools 1 609 92A 2UL | (15.4.16)

Safety Warnings for Drills

 Wear ear protectors when impact drilling. Exposure to

noise can cause hearing loss.

 Use auxiliary handle(s), if supplied with the tool. Loss

of control can cause personal injury.

 Hold power tool by insulated gripping surfaces, when

performing an operation where the cutting accessory

may contact hidden wiring or its own cord. Cutting ac-

cessory contacting a “live” wire may make exposed metal

parts of the power tool “live” and could give the operator an

electric shock.

 Use suitable detectors to determine if utility lines are

hidden in the work area or call the local utility company

for assistance. Contact with electric lines can lead to fire

and electric shock. Damaging a gas line can lead to explo-

sion. Penetrating a water line causes property damage or

may cause an electric shock.

 Switch off the power tool immediately when the tool in-

sert jams. Be prepared for high reaction torque that

can cause kickback. The tool insert jams when:

— the power tool is subject to overload or

— it becomes wedged in the workpiece.

 Hold the machine with a firm grip. High reaction torque

can briefly occur while driving in and loosening screws.

 When working with the machine, always hold it firmly

with both hands and provide for a secure stance. The

power tool is guided more secure with both hands.

 Secure the workpiece. A workpiece clamped with clamp-

ing devices or in a vice is held more secure than by hand.

 Always wait until the machine has come to a complete

stop before placing it down. The tool insert can jam and

lead to loss of control over the power tool.

 Products sold in GB only: Your product is fitted with a

BS 1363/A approved electric plug with internal fuse

(ASTA approved to BS 1362).

If the plug is not suitable for your socket outlets, it should

be cut off and an appropriate plug fitted in its place by an

authorised customer service agent. The replacement plug

should have the same fuse rating as the original plug.

The severed plug must be disposed of to avoid a possible

shock hazard and should never be inserted into a mains

socket elsewhere.

Products sold in AUS and NZ only: Use a residual current

device (RCD) with a rated residual current of 30 mA or

less.

Product Description and Specifica-

tions

Read all safety warnings and all instruc-

tions. Failure to follow the warnings and in-

structions may result in electric shock, fire

and/or serious injury.

Intended Use

The machine is intended for impact driving in brick, concrete

and stone, as well as for drilling in wood, metal, ceramics and

plastic.

Product Features

The numbering of the product features refers to the illustra-

tion of the machine on the graphics page.

1 Key type drill chuck

2 “Drilling/Impact Drilling” selector switch

3 Handle (insulated gripping surface)

4 Lock-on button for On/Off switch

5 On/Off switch

6 Chuck key

Accessories shown or described are not part of the standard deliv-

ery scope of the product. A complete overview of accessories can

be found in our accessories program.

Technical Data

Assembly

 Before any work on the machine itself, pull the mains

plug.

Changing the Tool

 Wear protective gloves when changing the tool. The

drill chuck can become very hot during longer work peri-

ods.

Key Type Drill Chuck (see figure A)

– Open the key type drill chuck 1 by turning until the tool can

be inserted. Insert the tool.

– Insert the chuck key 6 into the corresponding holes of the

key type drill chuck 1 and clamp the tool uniformly.

Impact Drill GSB 451

Article number

3 601 B16 0..

Rated power input

W450

Output power

W250

No-load speed

min

-1

2600

Impact rate

min

-1

25700

Rated torque

Nm 1.5

Spindle collar dia.

mm 43

Max. drilling dia.

–Concrete

– Steel

– Wood

mm

mm

mm

10

8

20

Chuck clamping range

mm 1.5–10

Weight according to

EPTA-Procedure 01:2014

kg 1.5

Protection class

/II

The values given are valid for a nominal voltage [U] of 230 V. For differ-

ent voltages and models for specific countries, these values can vary.

OBJ_BUCH-2766-002.book Page 5 Friday, April 15, 2016 12:42 PM
