6 | English
English
Safety Instructions
All instructions must be read and observed
in order for the measuring tool to function
safely. The safeguards integrated into the
measuring tool may be compromised if the
measuring tool is not used in accordance with these in-
structions. Never make warning signs on the measuring
tool unrecognisable. SAVE THESE INSTRUCTIONS FOR
FUTURE REFERENCE AND INCLUDE THEM WITH THE
MEASURING TOOL WHEN TRANSFERRING IT TO A THIRD
PARTY.
u Warning! If operating or adjustment devices other
than those specified here are used or other proced-
ures are carried out, this can lead to dangerous expos-
ure to radiation.
u The measuring tool is delivered with a laser warning
sign (marked in the illustration of the measuring tool
on the graphics page).
u If the text of the laser warning label is not in your na-
tional language, stick the provided warning label in
your national language over it before operating for the
first time.
Do not direct the laser beam at persons or
animals and do not stare into the direct or
reflected laser beam yourself. You could
blind somebody, cause accidents or damage
your eyes.
u If laser radiation hits your eye, you must close your
eyes and immediately turn your head away from the
beam.
u Do not make any modifications to the laser equip-
ment.
u Do not use the laser goggles (accessory) as protective
goggles. The laser goggles make the laser beam easier to
see; they do not protect you against laser radiation.
u Do not use the laser goggles (accessory) as
sunglasses or while driving. The laser goggles do not
provide full UV protection and impair your ability to see
colours.
u Have the measuring tool serviced only by a qualified
specialist using only original replacement parts. This
will ensure that the safety of the measuring tool is main-
tained.
u Do not let children use the laser measuring tool unsu-
pervised. They could unintentionally blind themselves or
other persons.
u Do not use the measuring tool in explosive atmo-
spheres which contain flammable liquids, gases or
dust. Sparks may be produced inside the measuring tool,
which can ignite dust or fumes.
Keep the measuring tool and the magnetic
accessories away from implants and other
medical devices, e.g. pacemakers or insulin
pumps. The magnets inside the measuring tool
and accessories generate a field that can impair
the function of implants and medical devices.
u Keep the measuring tool and the magnetic accessor-
ies away from magnetic data storage media and mag-
netically sensitive devices. The effect of the magnets in-
side the measuring tool and accessories can lead to irre-
versible data loss.
Product Description and
Specifications
Please observe the illustrations at the beginning of this oper-
ating manual.
Intended Use
The measuring tool is intended for determining and checking
horizontal and vertical lines and plumb points.
The measuring tool is suitable for indoor use.
Product Features
The numbering of the product features shown refers to the il-
lustration of the measuring tool on the graphic page.
(1)
Laser beam outlet aperture
(2)
Battery compartment cover locking mechanism
(3)
Battery compartment cover
(4)
Serial number
(5)
Laser warning label
(6)
Fastening grooves of measuring tool
(7)
On/off switch
(8)
Spirit level of rotating platform
(9)
5/8" tripod mount of rotating platform
(10)
Height adjustment screw of the rotating platform
(11)
Fine adjustment screw of the rotating platform
(12)
Rotating platform
(13)
Fastening grooves of the rotating platform
(14)
Pendulum lock indicator
(15)
Status indicator
(16)
Vertical mode button
(17)
Horizontal mode button
(18)
Tripod adapter
a)
(19)
1/4" tripod
a)
(20)
Laser goggles
a)
(21)
Magnet
a)
(22)
Laser target plate
a)
(23)
Protective bag
1 609 92A 4HL | (08.02.2021) Bosch Power Tools
