Bruksanvisning

Water inlet installation

Maintenance

Maintenance methods

Parts name

How to use drainpipe

Installation and adjustment

Please install and adjust the machine according to the requirements of the manual.

Correct operation is very important for your safety.

Unpacking

Unpack the carton and take out the bottom cover.

Open the top lid of washing machine and take out all of the accessories.

Remove all wrappers, including the polystyrene base.

You are advised to keep all the packaging for reuse in case the machine is to be

transported again.

Positioning

The distance between the washing machine and the wall should be more than 50mm,

and the maximum allowed angle of the shank base of the machine is 1°.

The slanting or rough ground may cause operating stopped or unstable, please adjust it

with the following methods:

Horizontal checking

Observe the water bubble in balancing apparatus

is in red circle or not. In red circle, it is horizontal.

Adjust the adjustable foot

1) Lift up the adjustable foot gently, loose the adjustable nut

and twist the adjustable foot.

2) Fasten the nut after adjustment.

3) Set the machine flat, and observe again. If the water

bubble is not in red circle, repeat the above procedure,

till the water bubble is in red circle.

Installing the bottom cover

Let the back of washing machine incline forward,

make the side of bottom cover with sticker description

back to washing machine, insert to the bottom of

washing machine along the direction of arrow.

Remove two fixing clamp by scissors, insert to the

accordingly holes black lines indicating ( gently pull

fixing clamp should not be pulled out ), make the

bottom cover fixed on the base.

1°

Adjustable nut

Adjustable

foot

Fixing clampScissors

Bottom cover

The base

Troubleshooting

Notes ：If there is still a fault after the above checks, please pull out the plug and

contact the seller right away. It is dangerous to repair this product by

yourself.

Normal

Normal

Close the top lid

Close the top lid

Control panel has

no display

Plug is not inserted tightly

No electricity in the socket

Power switch is not turned on

Power supply is cut off

Inlet hose leaks

Inlet hose connector(connecting

with the tap)is not fixed tightly

Inlet hose and washing machine

connector is loose

Before contacting the technicians, please make the following checks:

Phenomena Possible reason

It does not drain

Water outlet of drainpipe is higher

than 1.2m

Drainpipe is bended or get blocked

No inflow of water

No water supply

Tap is not open

Inlet hose gets blocked

Spin stops and

water inflow begins

during spin program

Laundries is too much or too little

or the Machine is not place stably

Press the program

button to select

SPIN, but It does

not spin

Top lid was not closed when drain

is finished

Top lid was open when drain is

started

The spin is intermittent

when spin starts

Balance the laundries to reach to

the best spin effect

First time use, some

water flows out from

the drainpipe

The remaining water from factory’s

testing

Insert the plug tightly

Check the socket or change to

another socket

Press power switch

Check power supply

Install the inlet hose again

Tighten the connector of the

machine

The height of the drainpipe

should be less than 1.2m

Straighten or clean the drainpipe

Restart when water supply is

resumed

Open the tap

Clean the filter according to

before“clean inlet gate”

The machine is adjusting

automatically

Troubieshooting

1. After using the machine, you are advised to turn off the water taps. (if necessary, pull out

the inlet hose).

2. Do not keep water in tub for a long time. When washing is finished, drain it right away.

3. Once you have finished using the machine, you are advised to unplug it.

4. Put the electric cable and the drain hose in order.

5. Wipe the water on the surface and in the tub with soft cloth and keep the top lid opening for a

while. It helps to prevent mold and smell forming inside the appliance.

If the water in the inner tub has possibility to freeze, please do like below:

1. In winter, if remaining water freeze can cause the washing machine trouble, please take off the

water inlet hose and drain out the water in the hose and inner tub.

2. If the water freeze, please don't operate the washing machine. Put 40℃ hot water in the tub,

the hot water should submerge the pulsator, after a few minutes, rotate the pulsator by hand

gently, then you can operate the washing machine.

Control panel instructionsControl panel instructions

1.the drainpipe must be hanged during use, the height is

not more than 1.2m to avoid leakage or stop, if drain a

long time, the machine will stop running.

2.You can adjust the situation of the elbow bend pipe to

change the height of the drainpipe.

3.Do not extrude the drainpipe to ensue drain smoothly.

Cautions:When install the washing machine, please use the new hose assy along with

the washing machine, old hose assy can not reuse.

Tap selection

Check the connection between inlet

hose connector and the tap

Connect the inlet hose with the washing machine

1. Swing the inlet hose gently to confirm if it is

fastened.

2. After installation,open the tap and check if

it leaks.

3. Do not bend the inlet hose with overstrain.

4. Before each usage,check the connection

between inlet hose connector and the tap.

Make sure they are firmly fitted to prevent

dropping from improper installation position.

1. Do not take off the water absorption cushion. Please

check if the cushion is dropped or damaged before

each usage. If it is, contact the seller immediately.

2. Put the inlet hose nut on the inlet valve connector.

3. Fasten the inlet hose nut and swing it gently to make

sure if it is suitable.

Inlet valve connector

Inlet hose nut

Water absorption cushion

Suitable tap

The front end should be longer than 10mm. The tap exit end

face should be flat and smooth, if not file it to avoid leakage.

Not suitable tap

At the beginning of start, pressing WATER LEVEL, at the same time press

PRESET, you can select WATER RECYCLE, LOW NOISE, LOW NOISE-WATER

RECYCLE. Only both RINSE and SPIN are selected, WATER RECYCLE can be

selected. Once LOW NOISE is selected, program default setting is NORMAL and

PROGRAM button is locked.

During working, press WATER LEVEL and PRESET to set CHILD LOCK, press

again to unlock this function.

Before washing, the Digital Timer shows the set time, unit is Hour.

If selecting AIR DRY, the Digtal Timer displays air dry time, unit is

Minutes.

When washing, the Digital Timer shows the remaining time of

washing, unit is Minutes

When trouble encountered, the Digital Timer shows trouble code.

When it is ON and if with Fuzzy logic,the Digital Timer shows "--".

To switch on the Washing Machine to working state or waiting state.

Select one program form NORMAL, HEAVY, SOFT, STANDARD, FAST, WOOL,

CHILD, FOAM CLEAN, TUB CLEAN and AIR DRY.

If choose "STANDARD" program, the wash time is "9 minutes", spin times is "2",

spin time is "5 minutes", you can cancel one of the process .

If choose "FAST" program, the wash time is "9 minutes", spin times is "1", spin time

is"3 minutes", you can cancel one of the process (but if you choose "SOAK", the

wash time can not be cancelled)

If no selection is selected, the process will start with the NORMAL program when the

"START/PAUSE" button is pressed.

After selecting the PROGRAM, PROCESS and WATER LEVEL, press this button

to start. Press this button to pause during working, press again to continue.

Press "TEMP SELECT" to select "HOT" 、"COLD" or "WARM" water for wash.

During the rinse process, it will inlet cold water.

At the beginning of start, if with FUZZY logic and do not select water level, the

digital timer shows "- -". At this time, before press START/PAUSE, If select

NORMAL or HEAVY, with fuzzy logic. When select STANDARD, no fuzzy logic,

the water levelis 7"；When select FAST, no fuzzy logic, water level is "2". If no

WASH process, no fuzzy logic.

At the beginning of start, press WATER LEVEL to select water level, at this time,

no fuzzy logic function, you can select appropriate water level. According to your

laundries quantity.1-2 is low water level, 3-6 is middle water level,7-10 is high

water level.

During wash (including rinse), if need to add water, press WATER LEVEL button

to add water, un-press will stop adding. Or PAUSE the washing machine and

press WATER LEVEL to select higher water level, then press START/PAUSE

button, The washing machine Will add the water to setting level automatically and

continue working. If your resetting water level is lower than present water level,

the lower water Level will valid in next water inlet.

Automatically add water: during SOAK, WASH and RINSE process, if the washing

machine check the water level is lower than setting water level, The washing

machinewill pause and add water to setting water level automatically.

DIY (Do it yourself) program---- you can set spin time.

At the beginning of start, the spin time setting is "7 minutes".

At the beginning of start, you can press "SPIN" to set spin process only, press

"SPIN" again to set spin time.

DIY (Do it yoursef) program---- you can set rinse times.

At the beginning of start, the rinse times setting is "2 times".

DIY (Do it yoursef) program---- you can choose soak function and wash time.

Pressing "WASH" button for 2 seconds to choose soak function, pressing for 2

seconds again to cancel soak function.

Under "NORMAL", " HEAVY" programs to choose soak function, the soak is

before wash.

At the beginning of start, the wash time is "15 minutes".

Put through the power, press POWER button, the machine is in the state of beginning of start:

1.If there is no water in inner tub, washing machine is in " FUZZY" condition, washing time is

"15 minutes", rinse time is "2 times", spin time is "7 minutes", water level and preset are

displayed "--", program is "NORMAL" If press "START/APAUSE" button (or press

"PROGRAM" to select "HEAVY" ), the washing machine will start to sense and

automatically sense the weight of laundries and set water level.

2.If there is water in inner tub, the washing machine is not in "FUZZY" condition, washing time

is"15minutes", rinse time is "2 times", spin time is "7 minutes", water level is "7", program is

"NORMAL", digital time displays the time to finish washing.

At the beginning of start, press this button to select preset time from 2-24 hours.

If want to cancel preset time, press POWER to make the washing machine in

waiting state.

If need to select air dry, please press "PROGRAM" button to select airy dry, then

press this button to set air dry time.

1. pull out magic filter

2. open the box and clean it

3. close it and reinstall it

4. check if the lint block part is in good

condition

Magic filter cleaning

press this part and pull out

to take out the magic filter

lint block part (black rubber)

After the end of the programme

Clean the lint filter

The machine stops automatically, and

music buzzer will remind you to take out

the laundries or start again.

Once you have finished using the machine,

you are advised to unplug it and turn off the

water taps to avoid unexpected leak or fire.

External cleaning

Clean the exterior cabinet of the appliance with

soft cloth. Do not use cleanser, volatile

chemical materials to clean the machine, which

will damage plastic parts and the surface.

It is possible that the inlet filter net can be blocked by

the dust, please clean it according to the following

steps:

1. Close the tap and turn on the power switch.

2. Start the washing machine for 5 seconds(make

the water in the inlet hose flows to the tub), and

cut off the power supply.

3. Pull off the inlet hose, remove and clean the inlet

valve and the inlet net, and install again.

Drainpipe

Elbow

Less than 1.2m

Top lid

Top frame

Detergent box

Lint filter

Control panel

Inner tub

Pulsator

balancing

apparatus

Body

Base

Adjustable foot

Bottom cover

(1pc)

Accessories

Outfall stopper

(1pcs)

The end connect to

the appliance

Water inlet hose (2pc)

The end connect to

water inlet hose connector

Hot Water inlet valve

Cold Water inlet valve

Power cord

Back cover

Foot wheel(2pcs)

Fixing foot(2pcs)

Drainpipe

Betyg

Mer om denna bruksanvisning

Vi förstår att det är trevligt att ha en pappersbruksanvisning för din BEKO WTL160G Tvättmaskin. Du kan alltid ladda ner bruksanvisningen från vår hemsida och skriva ut den själv. Om du vill ha en originalbruksanvisning rekommenderar vi att du kontaktar BEKO. De kanske kan tillhandahålla en originalbruksanvisning. Letar du efter bruksanvisningen för din BEKO WTL160G Tvättmaskin på ett annat språk? Välj ditt föredragna språk på vår hemsida och sök efter modellnumret för att se om vi har det tillgängligt.

Specifikationer

Alla bruksanvisningar för BEKO Tvättmaskiner
Fler bruksanvisningar för Tvättmaskiner

Vanliga frågor om BEKO WTL160G Tvättmaskin

Vårt supportteam söker efter användbar produktinformation och svar på vanliga frågor. Om du hittar en felaktighet bland våra vanliga frågor uppskattar vi om du meddelar oss detta via vårt kontaktformulär.

Relaterade produkter

Bruksanvisning

BEKO BAW 208 Tvättmaskin

Bruksanvisning

BEKO WMB 61042 PT Tvättmaskin

Bruksanvisning

BEKO B3WFU50940BCI Tvättmaskin

Bruksanvisning

BEKO B7WFU69418MG ES Tvättmaskin

Bruksanvisning

BEKO BM3WFT31041WB Tvättmaskin

Bruksanvisning

BEKO BM3WFU4841WW Tvättmaskin

Bruksanvisning

BEKO BM3WFT3841B1 Tvättmaskin

Bruksanvisning

BEKO WY104344W Tvättmaskin

Relaterade kategorier
