Bruksanvisning Aurora AX-595PK Räknemaskin

Bruksanvisning

1

AURORA OPERATING MANUAL

For use with AX-595

Printed in China

9220260

Removing and Replacing the Calculator’s Cover

Always slide the keyboard end of the unit into the cover first. Never slide the

display end of the unit into the cover.

Holding the cover as shown in the illustration, slide the unit out of the cover

1

Holding the cover as shown in the illustration, slide the unit out of the cover after

2

Precautions

            

temperatures or dusty environments.

 Don

 Use a soft cloth to clean the machine. Do not use detergents.

Display (TrueView Dot Matrix Display)

<Status Indicators>

S : Shift key

A : Alpha key

M : Independent memory

STO : Store memory

RCL : Recall memory

STAT : Statistics mode

D : Degree Mode

R : Radian Mode

G : Gradient Mode

FIX : Fixed-decimal setting.

SCI : Scientific Notation

Maths : Math Display mode

▲ :Scroll Up

 : Scroll Down

 : Scroll Left

 : Scroll Right

Disp :Multi-statements Display

Before Using the Calculator

 Check the current Calculation mode

Be sure to check the status indicators that indicate the current calculation mode

( COMP, STAT, TABLE), display formats setting and angle unit setting ( Deg, Rad,

Gra).

 Return to initial setup

Pressing Shift CLR 1 （setup） = (Yes) CA to return the initial calculator

setup.

Calculation mode : COMP

Input/ Output Format : Maths

Angle unit : Deg

Display Digits : Norm 1

Fraction Display Format : d/c

Statistical Data Input : OFF

Decimal Point format : Dot

This action will not clear the variable memories.

 Initialize the calculator

When you are not sure of the current calculator setting, you are recommended

 

reply and variable memories), and LCD contrast by pressing Shift CLR 3 (All) =

( Yes ) CA .

Getting Started

Power On and Off

 First time operation:

Press ON Shift CLR 3 = CA to reset the calculator.

Power ON: When ON is pressed.

Power OFF: Shift OFF are pressed.

Display Contrast Adjustment

Press Shift SET-UP  5 (5:  CONT  ), enter the Display Contrast

Adjustment screen.

Press  to make the display contrast darken.

Press  to make the display contrast lighten.

Press CA or ON to confirm and clear the screen.

Auto Power Off Function:

When the calculator is not used for about 7 minutes, it will automatically power

off.

 To initialize the LCD contrast, press Shift CLR 3 = CA outside the

Display Contrast Adjustment screen.

Mode Selection

 Press MODE to enter the Calculation Mode Selection screen.

 Press 1 , 2 , 3 to select the calculation mode.

 .

Mode

LCD

Indicator

Operation

Normal calculation

COMP

MODE 1

Statistical calculation

STAT

STAT

MODE 2

Function Table calculation

TABLE

MODE 3

 Initial mode is COMP mode.

Calculator Set-up Menu

 Press Shift SET-UP to enter the Calculator Set-up Menu; press  /  for

next/previous page.

Press or  key

 To select the calculator input & output format [1] Maths or [2] Line.

[1] Maths-( Maths mode): The Maths mode

majority of calculation input

and output ( e.g. Fraction, pi,

square root number) are shown

in Mathematics textbook format.

And Maths icon will be shown.

[2] Line-( Line mode): The majority Line mode

of calculation input and output are

Shown in the lines format.

 To select the angle unit [3] Deg, [4] Rad or [5] Gra

[3] Deg: Angle unit in Degree

[4] Rad: Angle unit in Radian

[5] Gra: Angle unit in Gradient

90°= =100 grads

 To select display digit or notation [6] Fix, [7] Sci or [8] Norm

[6] Fix: Fixed Decimal, [Fix 0~9?] appears, specify the number of decimal places

by pressing [0] ~ [9].

Example: 230 ÷ 7 =32.8571 (FIX 4)

=32.86(FIX 2)

[7] Sci: Scientific Notation, [Sci 0~9?] appears, specify the number of significant

digits by pressing [0]~[9].

CONTRAST

LIGHT DARK

[ ] []

1:COMP 2:STAT

3:TABLE

1:ab/c 2:d/c

3:STAT 4:Disp

5: CONT 

1:Maths 2:Line

3:Deg 4:Rad

5:Gra 6:FiX

7:Sci 8:Norm

radians

2

π

4+2

2

6

2

Maths

(5+1) (3-1)

1.224744871
