Wireless Bicycle

Computer

Art.no 31-9474 Model 401-KS17XSL

Please read the entire instruction manual before using the

product and save it for future reference. We reserve the right for

any errors in text or images and any necessary changes made

to technical data. If you have any questions regarding technical

problems please contact Customer Services.

Product description

Features:

• Current speed (0–99.9 km/h or mph)

• Trip distance (0–999.99 km or miles)

• Odometer (0–999.99 km or miles)

• Odometer save. The odometer can be reset after battery

changes or if the cycle computer is reset to factory settings

• Automatic trip timer (up to 9:59:59 hours)

• Max speed (up to 99.9 km/h or mph)

• Clock (12/24 hour)

• Average speed (0–99.9 km/h or mph)

• Auto scan (shows trip distance, max speed,

average speed and trip time)

• Freeze function (freezes values of trip distance,

average speed and trip time)

• Relation to (over or under) average speed

• Speed tendency; accelerating or decelerating

• Service program

• Temperature (-10 ºC to +50 ºC or 14 to 122 ºF)

• Approximate calorie burn

• Solar cell panel

• Backlight

Contents

1. Computer

2. Sensor

3. Computer cradle

4. Batteries for the computer

and sensor (2 x CR2032, 3 V)

5. Magnet

6. 4 cable ties

Assembly

1. Attach the bracket to the handlebar. Make sure that the

rubber spacer is between the bracket and the handlebar

and that the snap buckle is facing the saddle.

2. Insert a battery into the sensor and attach

it to the front fork. Make sure that it is

facing the spokes. NB Don’t completely

tighten the cable ties straight away. You

might need to adjust the sensor angle a

little after the magnet has been fitted.

3. Attach the magnet

to one of the spokes

(the clamp fits different

spoke thicknesses). 

4. Adjust the magnet and the sensor so that they face each

other, max 2 mm apart.

5. Insert the battery into the computer, making

sure that the + is facing upwards.

6. Slide the computer into the bracket until it

clicks into place. To remove the computer,

press in the snap buckle and lift out

the computer.

Computer setup

1. Shows which menu is open. This field is empty

in setup mode.

2. Shows if speed is increasing (wheel spins forwards)

or decreasing (wheel spins backwards).

3. Solar cell (auxiliary power for the battery)

4. + appears if speed is above average speed;

– appears if speed is below average speed

5. Shows current speed

6. Clock

7. Settings button (right)

8. Settings button (left) / Backlight

The following settings must be made when

the battery is inserted for the first time or

after the computer has been reset

to factory settings:

Wheel size input

Use the table on the right to set the correct wheel factor.

Wheel Circum-

diameter ference of

wheel (mm)

---------------------------------------

20″ 1596

22″ 1759

24″ 1916

26″ (650A) 2073

26.5″ (Tubular) 2117

26.8″ (700x25C) 2124

26.8″ (700x28C) 2136

27″ (700x32 C) 2155

28″ (700B) 2237

(w/tire)

Wheel Circum-

diameter ference of

wheel (mm)

-------------------------------------------

ATB 24″x1.75 1888

ATB 26″x1.4 1995

ATB 26″x1.5 2030

ATB 26″x1.75 2045

ATB 26″x2 (650B) 2099

27″x1 2136

27″x1 1/4 2155

For example, if the wheel is 26″ the input factor is 2073. Set the

factor with the right button and change digits with the left button.

When the wheel factor has been entered, go to the next menu by

pressing the left button. Display shows: 

Km or miles

Select with the right button, confirm and advance with the left

button to:

Age and weight

Set age and weight with the right button

and advance with the left button. If you se-

lected km in the previous menu, the weight

will appear in kg. If you selected miles in the

previous menu, the weight will appear in

pounds. Advance with the left button to:

Reminder to service your bicycle

200, 400, 600 or 800 km. A spanner flashes

in the display when the preset distance has

been reached. Press the left button to stop

the spanner flashing. Select the desired

distance using the right button. Advance

with the left button to:

NOTE!If you begin any of the above settings and do not confirm

them, the computer shuts off automatically after 5 minutes.

Pressing any button will turn the computer back on and revert

to the wheel size input setting.

Setting the clock

Hold in the left button for 2 seconds to enter the clock setting.

Select a 12 or 24 hour display using the right

button. Press the left button to adjust the

time. Change the hours with the right button

and advance to the minutes with the left

button. Change the minutes with the right

button. Press the left button when you have

finished (the minutes stop flashing).

NOTE!Press the right button to advance

through the menus:

ODO: Odometer

Holding in the left button for 2 seconds

while in ODO menu will take you to:

Odometer reset

In order to restore the total distance travelled

following battery changes, adjust the value

with the right button and move with the left

button as before. Press the left button to

go back to ODO. Press the right button to

advance to:

DST: Trip distance. Holding in the left button

for 2 seconds while in DST menu will zero-

reset the trip distance, trip timer and average

speed. Press the right button to advance to:

MXS: Max. speed

Holding in the left button for 2 seconds will

zero-reset the max speed. Press the right

button to advance to the next menu:

AVS: Average speed

Holding in the left button for 2 seconds while

in DST menu will zero-reset the average

speed. Press the right button to advance to:

TM: Trip time

Holding in the left button for 2 seconds while

in DST menu will zero-reset the trip time.

Press the right button to advance to:

Temperature

Holding in the left button for 2 seconds will

show the selection of ºC or ºF, select using

the right button, confirm with the left button.

Advance with the right button to:

CAL: Calories

Hold in the left button for 2 seconds to zero-

reset. Press the right button to advance to:

AUTO SCAN

The display alternates between trip distance,

max speed, average speed and trip timer

every 4 seconds. Press the right button to

exit the setup menus.

Freeze function

When you have finished cycling three values can be frozen: Trip

distance, average speed and trip time. Press the left button once,

the trip time will start to flash. Press the right button to read the

average speed and press the right button again to read the trip dis-

tance. Keep pressing the right button to alternate between these

three values. Press the left button to go back to the setup mode.

Resetting the computer to factory settings

The computer resets if:

• The battery is removed.

• The left and right buttons are held in together for 2 seconds.

On/Off

• Turn the computer on by pressing any button.

• If the computer is not used for 5 minutes it shuts off automatically

to preserve the battery. Pressing any button will turn the computer

back on again.

Troubleshooting guide

No speedometer

reading.

• Check distance between magnet

and sensor.

The display is sluggish. • It is too cold, the working temp

is 0–55 ºC.

Black display. • The temperature is too high.

• Display has been exposed to

sunlight too long.

The symbols on the

display are weak.

• Check the battery in the sensor

and the computer and make sure

that they are correctly inserted.

• Replace the batteries if necessary.

No trip distance display. • Check distance between magnet

and sensor.

• Check the battery in the sensor

and the computer and make sure

that they are correctly inserted.

• Replace the batteries if necessary.

Display shows

irregular figures.

• Remove the battery and

insert it again.

The computer is reset

by external interference.

• Remove the battery and

insert it again.

Disposal

Follow local ordinances when disposing of this product. If you

are unsure of how to dispose of this product, please contact

your local authority.

max 2 mm
