Bruksanvisning Asaklitt 36-5998 Ficklampa

Bruksanvisning

GREAT BRITAIN • CUSTOMER SERVICE

tel: 020 8247 9300 e-mail: [email protected].uk internet: www.clasohlson.co.uk

ENGLISH

1 2 3 4

5

6 7 8 9

Ver. 20150505

Rechargeable

Pocket Torch

Art.no 36-5998 Model N-003

Please read theentire instruction manual before using

theproduct and then save it for future reference. We reserve

theright for any errors in text or images and any necessary

changes made to technicaldata. If you have any questions

concerning technical problems please contact our Customer

Services.

Safety

• Do not point thelight beam into anyone’seyes.

• Do not let children play with theproduct.

• Never charge thetorch in combustible atmospheres or

on flammable surfaces.

• Warning: Onlyuse type 18650 rechargeable batteries.

• Use only theprovided charger cable, connected to

aUSB port, for charging thetorch.

• Never use adefective chargercable.

• Never expose thetorch to rain/moisture.

• Never expose thebattery to high temperatures or

nakedflames.

• Avoid contact with aleaking battery.

Care and maintenance

Clean thetorch using asoft, dampcloth.

Never use cleaning agents or other chemicals.

Disposal

This product should be disposed of in accordance with local

regulations. If you are unsure how to proceed, contact your

local council.

Product description

• Rechargeable pocket torch with anadjustable focus beam,

5W LED chip and aluminium housing.

• Thetorch is charged from aUSB outlet via theincluded

chargercable.

1. Lightbeam adjuster

2. Battery holder

3. Magnetic connector for charger cable

4. Powerswitch

5. Type18650 battery

6. Magnetic connector on chargercable

7. Charging indicator

8. Chargercable

9. USBport for connecting achargercable

Charging the torch

Thetorch has amagnetic charger cable connection.

Thetorch can only be charged using theincluded chargercable.

from aUSB port on acomputer for

example, thecharging time could be

twice aslong.

4. Thecharger cable attaches to thetorch

by magnetism, make sure that it is

positioned correctly.

Note: Thecharging time can

vary depending on the

charging source.

1. Unscrew thebattery

holder (2) and insert

theincluded rechargeable

type 18650 battery (5)

into it in accordance with

thepolarity markings

in thebattery holder.

Screwthebattery holder back into thetorch housing.

2. Connect thesupplied charger cable (8) to aUSB port/charger.

3. Place themagnetic connector on thecharger cable (6) onto

thecorresponding connector (3) on thetorch. Thecharging

indicator (7) shines red when thetorch battery is charging.

Whenthebattery is fully charged theindicator shinesgreen.

Thefirst time thebattery is charged, it will need at least

7½hours to fully charge (applies when using aUSB charger

providing acharging current of 1A). Ifthetorch is charged

Operating instructions

• Thetorch can be switched on/off using thepower

switch(4). Select thedesired mode by pressing

thepower switch therequired number oftimes:

highpower (200lm) – low power (100 lm) –off.

• Thetorch also has aboost-mode, in which thetorch

shines extra brightly (350lm). Theboost-mode is

activated as follows: Holdthepower switch down for

about 4 seconds until thetorch shines really brightly.

Theboost-mode lasts for about 60 seconds and then

thetorch enters high powermode.

• Adjust thelight beam by moving thelight beam

adjuster(1) forwards or backwards.

Specifications

Charging voltage 5 V DC from aUSB charger

(USB charger sold separately)

Battery li-ion, 2800 mAh (type 18650)

Operating time Up to 3 hours (on high),

up to 6 hours (on low)

Colour temperature 6000K

Colour rendition Ra 70

Power 5W

Lumens 350 lm (60 sec in boost-mode),

200 lm (high power),

100 lm (low power)

Operating temperature −20 to +50ºC

Size 155mm in length,

39mm in diameter

Weight 205g (incl. charger cable)
