5

ELECTRICAL CONNECTIONS

Electrical connection must be made before connecting the appliance to the

electricity supply. The appliance must be installed by a qualied electrician

who is fully aware of current safety and installation regulations. Specically,

installation must be carried out in compliance with the regulations of the local

electricity supply company. Make sure that the voltage shown on the rating

plate is the same as the power supply voltage in your home. Regulations

require that the appliance be earthed: use conductors (including the earth

conductor) of the appropriate size only. The manufacturer declines all liability

for injury to persons or animals and for damage to property resulting from

failure to observe the above regulations. For the electrical connection use a

H05RR-F type cable as indicated in the table below:

Power supply voltage.

Conductors Amount x size

220-240V ~ +

230-240V ~ +

380-425V 2N~ +

220-240V 3~ +

380-415V 3N~ +

3 x 4 mm

3 x 4 mm (Australia only)

4 x 1,5 mm

5 x 1,5 mm

4 x 1,5 mm

The appliance must be connected to the electricity supply by means

of an all-pole disconnect switch with minimum contact gap of 3 mm.

Attention: the power supply cable must be long enough to allow the cooktop to

be removed from the worktop and must be positioned so as to avoid damage

or overheating caused by contact with the base.

Connecting to the terminal board

Note: the yellow/green earth wire must be connected to the terminal with the

symbol and must be longer than the other wires.

• Remove approx. 70 mm of the cable sheath from the power supply cable

(B).

• Strip approx. 10 mm of sheath from the wires. Then insert the power supply

cable into the cable clamp and connect the wires to the terminal block as

indicated in the connection diagram placed close to the terminal block itself.

• Secure the power supply cable (B) by means of the cable clamp.

• Close the terminal board with the cover (A) securing it with the screw

provided.

• After the electrical connection, t the hob from the top and hook it to the

support springs, according to the illustration.

• Use pots and pans whose bottom diameter is equal to that of the cooking

zone or slightly larger.

• Only use at-bottomed pots and pans.

• If possible, keep pot lids on when cooking.

• Cook vegetables, potatoes, et. with little water in order to cut down cooking

time.

• A pressure cooker allows you to save even more energy and time.

ENERGY SAVING TIPS

NO!
