GB

12

! Before operating your new appliance please read this

instruction booklet carefully. It contains important information

for safe use, installation and care of the appliance.

! Please keep these operating instructions for future

reference. Pass them on to possible new owners of the

appliance.

Positioning

! Keep packaging material out of the reach of children. It

can become a choking or suffocation hazard (see

Precautions and tips).

! The appliance must be installed by a qualified professional

according to the instructions provided. Incorrect installation

may cause harm to people and animals or may damage

property.

! This unit may be installed and used only in permanently

• The room must be equipped with an air extraction system

that expels any combustion fumes. This may consist of a

hood or an electric fan that automatically starts each time

the appliance is switched on.

needed for combustion to occur normally. The flow of air

must not be less than 2 m

3

/h per kW of installed power.

The air circulation system may

take air directly from the outside

by means of a pipe with an inner

cross section of at least 100 cm

2

;

the opening must not be

vulnerable to any type of

blockages.

The system can also provide the

air needed for combustion

indirectly, i.e. from adjacent rooms

fitted with air circulation tubes as

described above. However, these

rooms must not be communal

rooms, bedrooms or rooms that

may present a fire hazard.

Fitting the appliance

• The installation cavity should have the dimensions

indicated in the figure. Fastening hooks are provided,

allowing you to fasten the hob to tops that are between

20 and 40 mm thick. To ensure the hob is securely

fastened to the top, we recommend you use all the

475

mm

55

mm

Installation

Enlarging the ventilation slot

between window and floor.

Adjacent

Room

Room to be

Vented

A

Examples of ventilation holes

for comburant air.

In a chimney stack or branched flue.

(exclusively for cooking appliances)

Directly to

the Outside

• The room must also allow proper air circulation, as air is

Gas inlet is located at the rear left hand side 25mm in from the rear edge.

hooks provided.

Front and rear clearance 5mm

Must be installed with the following clearances

This appliance must be installed by an authorised person in accordance with this instruction manual, AS/NZS 5601.1 – Gas installations

(installation

and pipe sizing), local gas fitting regulations, local electrical regulations, Building Code of Australia and any other government authority.

ventilated rooms

The following requirements must be

observed:

Side clearance 55mm

660mm
