3

To remove the utensil basket from the door

1. Grasp the silverware basket by the handle.

Slide it toward the top of the door.

2. Lift the basket off the securing knobs.

To replace the utensil basket in the door

1. Set the silverware basket on the securing

knobs.

2. Slide the basket toward the bottom of the door until it locks

into place.

Add Detergent

NOTE: If you do not plan to run a wash cycle soon, run a rinse

cycle. Do not use detergent.

■ Use automatic dishwasher detergent only. Add powder, liquid

or tablet detergent just before starting a cycle.

■ Fresh automatic dishwasher

detergent results in better

cleaning. Store tightly closed

detergent container in a cool,

dry place.

■ The amount of detergent to use depends on:

How much soil remains on the items - Heavily soiled loads

require more detergent.

The hardness of the water - If you use too little in hard water,

dishes won't be clean. If you use too much in soft water,

glassware will etch.

Soft to Medium Water (0-6 grains per U.S. gallon)

[typical water softener water and some city water]

Medium to Hard Water (7-12 grains per U.S. gallon)

[well water and some city water]

■ Depending on your water hardness, fill the Main Wash section

of the dispenser as shown. Fill the Pre-Wash section to the

level shown, if needed.

NOTE: Fill amounts shown

are for standard powdered

detergent. Follow

instructions on the package

when using other dishwasher

detergent.

Add Rinse Aid

■ Your dishwasher is designed to use rinse aid for good drying

performance. Without rinse aid your dishes and dishwasher

interior will have excessive moisture. The heat dry option will

not perform as well without rinse aid.

■ Rinse aid keeps water from forming droplets that can dry as

spots or streaks. They also improve drying by allowing water to

drain off of the dishes after the final rinse.

■ Rinse aid helps to reduce excess moisture on the dish racks

and interior of your dishwasher.

■ Check the rinse aid indicator. Add rinse aid when indicator

drops to “Refill” level.

■ To add rinse aid, turn the dispenser cap

counterclockwise and lift off. Pour rinse

aid into the opening until the indicator

window looks full. Replace the

dispenser cap and turn clockwise.

Make sure cap is fully locked.

NOTE: For most water conditions, the

factory setting of 2 will give good results. If you

have hard water or notice rings or spots, try a

higher setting. Turn the arrow adjuster inside the

dispenser by either using your fingers or inserting a

flat-blade screwdriver into the center of the arrow

and turning.

Select a Cycle (cycles vary by model)

NOTE: Heavier cycles and options affect cycle length. Some

cycles and options will take up to 3¹⁄₂ hours to complete.

Heavy Wash – Use for

heavily soiled, hard-to-clean

items.

Normal Wash – Use for

normal food soil. The energy usage label is based on this cycle.

Quick Wash – Use for prerinsed or lightly soiled loads.

Rinse Only – (no options apply to this cycle) Do not use detergent.

This is only a rinse that keeps food from drying on your dishes and

reduces odor buildup in your dishwasher until you are ready to

wash a full load.

Auto Wash – Use for automatically selecting the number of water

fills best suited for the soil level.

Select Options (options vary by model)

You can customize your cycles by pressing

the options desired.

Heated Dry – (automatic with all except

rinse cycle) use for best drying results. Turn off by pressing Heat

Dry so that the light goes off.

Sanitize – (use only with Normal wash cycle; automatic with Heavy

Duty cycle) Select this option to raise the water temperature in the

final rinse to approximately 155°F (68°C). Sanitize option adds heat

and time to the cycle. This high temperature rinse sanitizes your

dishes and glassware in accordance with NSF/ANSI Standard 184

for Residential Dishwashers. Certified residential dishwashers are

not intended for licensed food establishments.

Hi-Temp Wash – (use only with Pots & Pans and Normal wash

cycles) heats the water during the wash portions of the cycle.

DELAY Hours – (any cycle) offers the choice to start the

dishwasher automatically at a later time. Select a wash

cycle and options. Press DELAY Hours. Press START/

Cancel. Close the door firmly.

Locked – (on Heat Dry button) use to avoid unintended use of your

dishwasher. When Control Lock is lit, all buttons are disabled. The

dishwasher door can be opened while the controls are locked.

To turn on Lock:

Press and hold Heat Dry for 3 seconds. The Locked light glows. If

you press any pad while your dishwasher is locked, the light

flashes 3 times.

To turn off Lock:

Press and hold Heat Dry for 3 seconds. The Control Lock light

turns off.

■ When loading silverware, always place sharp

items pointing down and avoid “nesting” as

shown.

STEP 2

A. Cover latch

B. Main Wash section

C. Pre-Wash section

B

A

C

Soft Water

Hard Water

Soft Water

Hard Water

Main Wash Pre-Wash

STEP 3

¹⁄₄

turn to lock
