Bruksanvisning Aiwa XP-R220 Discman

Bruksanvisning

C

DC 2.4 V using two commercially available

(Ni-Cd 1.2 V 700 mAh) rechargeable batteries

AC house current using the supplied AC adaptor

Maximum outside dimensions

130 (W) × 30.5 (H) × 130 (D) mm

(excluding projecting parts and controls)

(5

1

/8 × 1

1

/4 × 5

1

/8 in.)

Weight Approx. 238 g (8.3 oz.) excluding batteries

Accessories AC adaptor AC-D603 (1)

Stereo headphones (1)

AC adaptor AC-D603U Rated input: AC 120 V, 60 Hz

The specifications and external appearance of this unit are subject to change

without notice.

USING ON DRY CELL BATTERIES → C

Open the battery compartment and insert two size AA (LR6) alkaline

batteries with the 0 and 9 marks correctly aligned.

Battery replacement

The battery indicator in the display changes from to to according

to the remaining power of the batteries. Replace the batteries when

lights.

If the unit remains in use after

lights, “Lo-bAtt” appears and operation stops.

To maintain preset data

When replacing the batteries, the unit will retain the preset station frequencies

for about 1 minute. To prevent the erasure of the memories, replace the batteries

within 1 minute.

• Before replacing the batteries, turn off the power by pressing

sSTOP/OFF/CHARGE.

Battery life (using alkaline batteries LR6)

Battery life may vary depending on conditions of use.

If the cover of the battery compartment comes off → D

Note on dry cell batteries

• Make sure that the 0 and 9 marks are correctly aligned.

• Do not mix the different types of batteries, or an old battery with a new one.

• To prevent the risk of electrolyte leakage or explosions, never recharge the

batteries, apply heat to them, or take them apart.

• When not using the batteries, remove them to prevent needless battery wear.

• If liquid leaks from the batteries, wipe thoroughly to remove.

D

The setting of the E•A•S•S switch Battery life

48 Approx. 27 hours

12 Approx. 21 hours

OFF Approx. 19 hours

OWNER’S RECORD

For your convenience, record the model number and the serial number (you

will find it inside the battery compartment of your set) in the space provided

below. Please refer to them when you contact your Aiwa dealer in case of

difficulty.

Model No.

Serial No.

NOTE

FOR USE IN THE U.S.A.

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation.

This equipment generates, uses, and can radiate radio frequency energy

and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee

that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can

be determined by turning the equipment off and on, the user is encouraged

to try to correct the interference by one or more of the following measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment and receiver.

– Connect the equipment into an outlet on circuit different from that to which

the receiver is connected.

– Consult the dealer or an experienced radio/TV technician for help.

CAUTION

Modifications or adjustments to this product, which are not expressly approved

by the manufacturer, may void the user’s right or authority to operate this

product.
