En

ENGLISH

3

Note to CATV system installer:

This reminder is provided to call the CA TV system installer ’s

attention to Section 820-40 of the NEC which provides guidelines

for proper grounding and, in particular , specifies that the cable

ground shall be connected to the grounding system of the

building, as close to the point of cable entry as practical.

Lightning

For added protection for this unit receiver during a lightning storm,

or when it is left unattended and unused for long periods of time,

unplug it from the wall outlet and disconnect the antenna or cable

system. This will prevent damage to the unit due to lightning and

powerline surges.

Maintenance

Cleaning - Unplug this unit from the wall outlet before cleaning.

Do not use liquid cleaners or aerosol cleaners. Use a damp cloth

for cleaning.

Damage Requiring Service

Unplug this unit from the wall outlet and refer servicing to qualified

service personnel under the following conditions:

1) When the power cord or plug is damaged.

2) If liquid has been spilled, or objects have fallen into the unit.

3) If the unit has been exposed to rain or water .

4) If the unit does not operate normally by following the operating

instructions. Adjust only those controls that are covered by

the operating instructions as improper adjustment of other

controls may result in damage and will often require extensive

work by a qualified technician to restore the unit to normal

operation.

5) If the unit has been dropped or the cabinet has been damaged.

6) When the unit exhibits a distinct change in performance - this

indicates a need for service.

Do not attempt to service this unit yourself as opening or removing

covers may expose you to dangerous voltage or other hazards.

Refer all servicing to qualified service personnel.

Replacement Parts - When replacement parts are required, be

sure the service technician has used replacement parts specified

by the manufacturer or having the same characteristics as the

original part. Unauthorized substitutions may result in fire, electric

shock or other hazards.

Safety Check - Upon the completion of any service or repairs to

this unit, ask the service technician to perform safety checks to

determine that the unit is in proper operating condition.

TABLE OF CONTENTS

IMPORTANT SAFETY INSTRUCTIONS ............................2

PREPARATIONS

CONNECTIONS .................................................................. 4

BEFORE OPERATION........................................................ 8

SOUND

CUSTOM AUDIO ADJUSTMENT ....................................... 9

DSP SURROUND................................................................ 9

BASIC OPERATIONS

SELECTION OF AUDIO/VIDEO SOURCE....................... 10

RECORDING AN AUDIO SOURCE ................................. 11

RADIO RECEPTION

MANUAL TUNING .............................................................12

PRESET TUNING .............................................................. 12

DOLBY SURROUND AND DTS SURROUND

TURNING SURROUND ON AND OFF ............................. 13

SETTING SPEAKER SIZE AND DISTANCE ...................14

ADJUSTING SPEAKER LEVEL BALANCE .................... 15

OTHER SETTINGS ........................................................... 16

TIMER

SETTING THE SLEEP TIMER .......................................... 17

GENERAL

CARE AND MAINTENANCE ............................................17

TROUBLESHOOTING GUIDE ..........................................17

SPECIFICATIONS .............................................................18

PARTS INDEX ...................................................................19

FM antenna Remote control AM antenna

Operating Instructions, etc.

Check your accessories

For the customers who bought the AV-NW31 (for HT-

NW300 and HT-DV2300)

• For the connections and operations of the speaker system

and the DVD player , refer also to the operating instructions

supplied with the speaker system (for HT -NW300 and HT-

DV2300) or the DVD player (for HT -DV2300).

• The optical connecting cord is also supplied to the system

HT-DV2300).

Video connecting cord

(AV-NW31 only)

Coaxial connecting cord

(AV-NW31 only)
