Bruksanvisning LG AG-S360 3D-glasögon

Bruksanvisning

ENGLISH

3

USING 3D GLASSES

Button Operation LED Indicator

Power On

Press and hold the power button for one to two

seconds.

The red LED indicator flashes once.

Power Off

Press and hold the power button for one to two

seconds until the LED indicator turns red.

The red LED indicator flashes three times.

Auto Off

*1

The product is automatically turned off if there

is no 3D signal for more than one minute.

The red LED flashes three times.

Battery discharge

-

The red LED flashes for one minute and

turns off automatically.

Re-syncing the Glasses

Press the power button for at least eight sec-

onds.

When the LED indicator turns green, release

the power button. The green LED indicator

flashes three times and turns off. If you turn

the power on again, the 3D glasses detect

the TV with the strongest signal.

*1

The Auto Off function automatically turns the power off when there is no signal between the TV and glasses for more than one

minute. You cannot watch 3D images when the Auto Off function automatically turns the power off. This can happen when the

distance or angle between the TV and glasses is out of range; when there is a barrier between the TV and glasses; or when the TV

is switched from 3D to 2D mode.

!

NOTE

▶ Make sure to turn off the 3D glasses when they are not in use. Otherwise, the battery life shortens.

ASSEMBLING THE GLASSES

The temple arms of the glasses are provided in the package. Attach them to the frame according to the in-

structions below.

1

Insert each arm into the frame in the direction shown in the

figure until it clicks.

!

NOTE

▶ Make sure that the left and right arms are attached to the corresponding side of the frame.

REPLACING THE BATTERY

The coin cell battery is not rechargeable. Please replace it when the red LED indicator flashes continuously.

1

2 3 4

Locate the battery cover. Press the cover slightly,

then lift it up.

Pull the cover open. Place the battery onto the

cover, then close the cover.

!

NOTE

▶ Make sure that the battery is inserted correctly with the plus sign facing towards the same sign marked

on the cover.

CAUTION

▶ Risk of explosion if battery is replaced by an incorrect type.

▶ dispose of used batteries according to the instruction.

ATTACHING THE NOSE PAD

Using 3D glasses may not be comfortable for users wearing regular eyeglasses. Adjusting the nose pad can

improve your viewing comfort.

1 2

- Pull the nose pad in the direction shown by the arrow in the

image. Be careful not to twist or lift the nose pad, as this can

cause damage.

- Remove the nose pad when the battery cover is fully closed.

!

NOTE

▶ Follow the instructions in reverse order to reattach the nose pad.

▶ The nose pad can be adjusted even if you are not wearing glasses.
