Bruksanvisning

E-23

Timekeeping

Use the Timekeeping Mode (

TIME

) to set and view the current time and date.

• Each press of

D

in the Timekeeping Mode will change screen contents as shown below.

l

l

l

l

l

l

l

l

l

Day of the week,

month/day screen

Barometric pressure change,

date (month/day) screen

Time (hour, minute,

second) screen

Hour Hand

Mode Hand

Second Hand

Minute Hand

Day of week Month Day

Barometric

pressure graph

Month Day

Hour : Minutes

E-22

General Functions (All Modes)

The functions and operations described in this section can be used in all of the modes.

Auto Return Features

• The watch automatically returns to the Timekeeping Mode from other modes if the crown is not pulled

out or if no button operation is performed for a preset amount of time.

Mode Name Approximate Elapsed Time

Digital Compass 1 minute

Data Recall, Alarm 3 minutes

Altimeter 1 hour minimum

12 hours maximum

Barometer, Thermometer 1 hour

Initial Screens

When you enter the Data Recall, Alarm, or World Time Mode, the data you were viewing when you last

exited the mode appears fi rst.

E-21

• Button operations are provided for direct access to the Timekeeping, Digital Compass, and Altimeter

modes.

Timekeeping Mode

Digital Compass Mode Altimeter Mode

E-20

Selecting a Mode

• The illustration below shows which buttons you need to press to navigate between modes.

• To return to the Timekeeping Mode from any other mode, hold down

B

for about two seconds.

Countdown Timer Mode

Stopwatch Mode

Alarm Mode

Data Recall Mode

World Time Mode

Thermometer Mode Barometer Mode

E-19

Mode Reference Guide

Your watch has 10 “modes”. The mode you should select depends on what you want to do.

To do this: Enter this mode: See:

• View the current time and date in the Home City

• Confi gure Home City and daylight saving time (DST) settings

• Confi gure time and date settings

Timekeeping Mode E-23

Determine your current bearing or the direction from your current location to a

destination

Digital Compass Mode E-32

• View the altitude at your current location

• Determine the altitude differential between two locations (reference point and

current location)

• Record an altitude reading with the reading time and date

Altimeter Mode

E-42

• View the barometric pressure at your current location

• View a graph of barometric pressure readings

•

Enable alerts (display and beep) for noteworthy changes in barometric pressure

Barometer Mode E-58

View the temperature at your current location Thermometer Mode E-67

Recall records created in the Altimeter Mode Data Recall Mode E-70

Use the stopwatch to measure elapsed time Stopwatch Mode E-74

Use the countdown timer Countdown Timer Mode E-76

Set an alarm time Alarm Mode E-78

View the current time in 29 cities (29 time zones) and UTC (Universal Coordinated

Time) time

World Time Mode E-81

E-18

Power Saving

When turned on, Power Saving enters a sleep state automatically whenever the watch is left for a certain

period in an area where it is dark. The table below shows how watch functions are affected by Power

Saving.

• For information about enabling and disabling power saving, see “To turn Power Saving on or off” (page

E-89).

• There actually are two sleep state levels: “display sleep” and “function sleep”.

Elapsed Time in Dark Hands and Display Operation

60 to 70 minutes (display sleep)

Blank display, second hand

stopped.

Except for display and second hand, all

functions enabled.

6 or 7 days (function sleep)

Blank display, all hands

stopped at 12 o’clock.

Except for timekeeping, all functions

disabled.

• The watch will not enter a sleep state between 6:00 AM and 9:59 PM. If the watch is already in a sleep

state when 6:00 AM arrives, however, it will remain in the sleep state.

• The watch will not enter a sleep state while it is in the Stopwatch Mode or Countdown Timer Mode.

• The watch will not enter a sleep state while barometric pressure change indication is enabled (page E-63).

To recover from the sleep state

Move the watch to a well-lit area, press any button, or angle the watch towards your face for reading (page

E-86).

E-17

Charging Times

Exposure Level (Brightness)

Daily

Operation

*1

Level Change *2

Level 5 Level 4 Level 3 Level 2 Level 1

Outdoor sunlight (50,000 lux) 8 min. 3 hours 25 hours 7 hours

Sunlight through a window (10,000 lux)

30 min. 7 hours 92 hours 25 hours

Daylight through a window on a

cloudy day (5,000 lux)

48 min. 11 hours 149 hours 40 hours

Indoor fl uorescent lighting (500 lux) 8 hours 135 hours – – – – – –

*1 Approximate amount of exposure time required each day to generate enough power for normal daily

operation.

*2 Approximate amount of exposure time (in hours) required to take power from one level to the next.

• The above exposure times all are for reference only. Actual exposure times depend on lighting

conditions.

• For details about the operating time and daily operating conditions, see the “Power Supply” section of

the Specifi

cations (page E-98).

E-16

Power Recovery Mode

• Performing multiple sensor, illumination, or beeper operations during a short period may cause the

recovery indicator (

RECOVER

) to start fl ashing on the display. This indicates that the watch is in the

power recovery mode. Illumination, alarm, countdown timer alarm, hourly time signal, and sensor

operations will be disabled until battery power recovers.

• Battery power will recover in about 15 minutes. At this time, the recovery indicator (

RECOVER

) will stop

fl

ashing. This indicates that the functions listed above are enabled again.

• Frequent fl ashing of the recovery indicator (

RECOVER

) indicates that battery power is low. Expose the

watch to bright light as soon as possible.

• Even if battery power is at Level 1 (

H

) or Level 2 (

M

), the Digital Compass Mode, Barometer Mode,

Thermometer Mode or Altimeter Mode sensor may be disabled if there is not enough power available.

This is indicated when the recovery indicator (

RECOVER

) is fl

ashing.

• Frequent fl ashing of the recovery indicator (

RECOVER

) probably means that remaining battery power

is low. Leave the watch in bright light to allow it to charge.

Operation Guide 5497
