Safety instructions

– Read and follow the operating and installation instructions and all other information

enclosed with the washing machine.

– Retain documents for subsequent use.

Risk of electric shock – Never pull out the mains plug by tugging on the power cord!

– Only insert/pull out the mains plug with dry hands.

Danger to life On redundant appliances:

– Pull out the mains plug.

– Sever the power cord and discard together with the plug.

– Destroy the lock on the washing-machine door. This will prevent

children from locking themselves in and putting their lives at risk.

Risk of suffocation – Keep packaging, plastic film and packaging parts out of the reach

of children.

Risk of poisoning – Keep detergents and care products out of the reach of children.

Risk of explosion – Caused by detergents containing solvents, e.g. stain remover/

items of laundry pretreated with solvent naphtha may result

in an explosion after being loaded into the washing machine.

Thoroughly rinse items of laundry by hand beforehand.

Risk of injury – Washing machine door may become very hot.

– Be careful when draining hot detergent solution.

– Do not climb on the washing machine.

– Do not lean on the washing machine door when it is open.

– Do not reach into the drum in case it is still rotating.

Consumption values

Programme

Temperature

[°C]

Buttons Load [kg] Water ** [l]

Energy **

[kWh]

Time ** [h]

 Cottons 40°C – 8.0 kg 74.2 l 0.97 kWh 2:38 h

 Cottons* 60°C – 8.0 kg 67.0 l 1.11 kWh 3:01 h

I Synthetics 30°C Ĉ Speed Perfect 3.5 kg 45.5 l 0.32 kWh 1:04 h

1

Mix

40°C Ĉ Speed Perfect 3.0 kg 42.1 l 0.50 kWh 0:45 h

 Delicate/Silk

cold – 2.0 kg 33.5 l 0.03 kWh 0:44 h

: Wool O cold – 2.0 kg 38.8 l 0.03kWh 0:38 h

* Programme setting with the maximum spin speed for labeling testing.

** The values deviate from the indicated values depending on water pressure, water hardness, and inlet temperature, ambient

temperature, type, amount and degree of soiling of the laundry, detergent used, fluctuations in the power supply and

selected additional functions.

*** The programme used for the evaluation of the captioned model under the Mandatory Water Efficiency Labelling Scheme

(MWEL) in Singapore is as follow:  Cottons 60°C.

8

9

Important information

Before using your washing machine for the first time

Do not put any laundry in the washing machine! Turn the tap on.

Pour into dispenser II:

– approx. 1 litre of water.

– Detergent (dosage according to manufacturer’s instructions for light soiling and according

to degree of water hardness).

Set the programme selector to . Drum Clean 90° and select $ Start/Reload.

At the end of the programme, set the programme selector to  Off.

Protecting the laundry and the machine

– When dosing all detergents, cleaning aids and cleaning agents, always follow the

manufacturer's instructions.

– Empty any pockets.

– Remove metal objects (paper clips, etc.).

– Wash delicates in the net/bag (tights, curtains, underwired bras).

– Close zips, button up covers.

– Brush sand out of pockets and collars.

– Remove curtain fittings or include in the net/bag.

Load the laundry

Load large and small items of laundry!

Do not jam items of laundry between the washing machine door and rubber seal.

Laundry with different degrees of soiling

Wash new items separately.

Light Do not prewash. If required, select the ĈSpeed Perfect option.

If required, pre-treat stains. If required, select the Prewash Cottons

programme.

Heavy Load less laundry. Select the Prewash Cottons programme.

Soaking Load laundry of the same colour.

Pour soaking agent/detergent into dispenser II according to the manufacturer’s instructions.

Set the programme selector to  Cottons 40 ° and select $ Start/Reload. After approx.

10 minutes, press $ Start/Reload to stop the programme. After the required soaking time,

re-press $ Start/Reload if the programme is to be continued, or change the programme.

Starching Laundry should not be treated with fabric softener.

Liquid starch can be used with all washing programmes. Pour starch into the fabric softener

dispenser ~ according to manufacturer’s instructions (if required clean beforehand).

Dyeing/bleaching

Dye in small quantities only. Salt may attack stainless steel. Follow the instructions of the dye

manufacturer. Do not bleach laundry in the washing machine.

10

Care/cleaning

ʑ

Machine housing, control panel

– Remove detergent residue immediately.

– Wipe with a soft, damp cloth.

– Do not clean the appliance with a water jet.

Clean the detergent drawer ...

... if it contains detergent or fabric softener residue.

1. Pull out, press the insert down, remove the drawer completely.

2. Remove the insert: using your finger, press the insert upwards.

3. Clean detergent dispenser and insert using water and a brush and dry

them.

4. Fit insert and lock it in place (push the cylinder onto guide pin).

5. Insert the detergent drawer.

Leave detergent drawer open so that residual water can evaporate.

ʑ

Drum

Leave washing machine door open so that the drum can dry out.

Rust stains – use chlorine–free cleaning agent, not steel wool.

ʑ

Descaling No laundry in the machine!

Not required if detergent dosed correctly. However, if this does occur, follow the instructions

of the descaling agent manufacturer. Suitable descalers can be purchased on our website

or from customer service. a Page 13

Information on the display panel depending on model

§j Door can be opened.

ǯ Door cannot be opened due to high temperature inside aWait for the temperature

to drop

The door cannot be opened due to high water level a Drain the water (e.g. select

the  Spin/Drain > programme).

§: ³Å Turn on the tap (cold water) fully;

Supply hose kinked/jammed, water pressure too low. aPage 11:Maintenance,

Filter in the water inlet hose blocked

§: ³µ Drain pump blocked a Page 11: Maintenance, Drain pump blocked

Drainage hose/outlet pipe blocked a Page 11: Maintenance, Drainage hose on the

siphon blocked

§: ´ Water in the base pan, appliance leaking. Turn off the tap. Call customer service!

'

If the childproof lock is active. Deactivate a Page 5

ª

Flashes if too much detergent is used. a Page 12

Other

displays

Switch off the appliance, wait 5 seconds and switch on again. If the display appears

again, call customer service. a Page 13

– Risk of electric shock. Pull out the mains plug.

– Risk of explosion. No solvents.

11

Risk of scalding.

– Allow detergent solution to cool down.

– Turn off the tap.

Maintenance

Drain pump blocked

Set the programme selector to  Off, pull out the mains plug.

1. Open the service flap.

2. Take the drainage hose out of the holder.

3. Remove sealing cap, allow the detergent solution to flow out. Have a

suitable container ready.

Insert the sealing cap and place the drainage hose back in its holder.

4. Carefully unscrew the pump cover (Caution! residual water).

Clean the interior, the pump cover thread and the pump housing (the fan

impeller in the detergent-solution pump must rotate).

5. Reinsert and screw on the pump cover. Handle should be vertical.

6. Close the service flap.

To prevent unused detergent from flowing into the outlet during the next

wash:

Pour 1 litre of water into dispenser II and start the  Spin/Drain

>

programme.

Drainage hose on the siphon blocked

Set the programme selector to  Off, pull out the mains plug.

1. Loosen the hose clip and carefully remove the drainage hose.

(Caution! Residual water.)

2. Clean the drainage hose and siphon spigot.

3. Re-attach drainage hose and secure connection point with hose clip.

Filter in the water inlet hose blocked

Risk of electric shock.

Do not immerse the Aqua-Stop safety device in water (contains electric valve).

Release the water pressure in the supply hose:

1. Turn off the tap.

2. Select any programme (except  Spin/Drain >// 2 Rinse).

3. Press $ Start/Reload button. Leave programme running for

approx. 40 seconds.

4. Set the programme selector to ÂOff. Pull out the mains plug.

Clean the filter:

5. Disconnect the hose from the water tap.

Clean the filter with a small brush.

and/or for standard and Aqua-Secure models:

remove the hose from the rear of the appliance.

Take out the filter with pliers and clean.

6. Connect the hose and check for leaks.

12

What to do if …

ʑ

Water is running out. – Correctly attach/replace the drainage hose.

– Tighten screw–fitting on the supply hose.

ʑ

Water not flowing in.

Detergent not washed in.

– $ Start/Reload not selected?

– Tap not open?

– Filter blocked? Cleaning the filter a Page 11

– Supply hose kinked or jammed?

ʑ

Washing-machine door

cannot be opened.

– Safety function active. Stop the programme? a Page 4

– - - - (Rinse hold = without final spin) selected? a Page 3, 4

– Can be opened via the emergency release only? a Page 13

ʑ

Programme does not

start.

– $ Start/Reload or Ready in  time selected?

– Door closed?

ʑ

Detergent solution is not

drained.

– - - - (Rinse hold = without final spin) selected? a Page 3,4

– Clean the detergent solution pump. a Page 11

– Clean the outlet pipe and/or drainage hose.

ʑ

Water not visible in the

drum.

– Not a fault - water below the visible area.

ʑ

Spin result is not

satisfactory,

laundry is wet/too damp:

– Not a fault – unbalanced load detection system has stopped the

spin cycle, laundry unevenly distributed.

Distribute small and large items of laundry in the drum.

– Too low speed selected? a Page 5

ʑ

The programme duration

changes during the wash

cycle.

– Not a fault – the programme sequence is optimised for the

particular washing process. This may result in changes to the

programme duration in the display field.

ʑ

Spin cycle actuated

several times.

– Not a fault - unbalanced load detection system adjusts

imbalance.

ʑ

Residual water in the

dispenser for care

products 0.

– Not a fault – effect of the care product not impaired.

– If required, clean the insert. a Page 10

ʑ

Odour forms in the

washing machine.

– Run the . Drum Clean 90° programme without laundry. Use

standard detergent.

ʑ

The status symbol ª

flashes. Foam may be

coming out of the

detergent drawer.

– Too much detergent used?

Mix 1 tablespoon of fabric softener with ½ litre of water and

pour into dispenser II.

(Not for outdoor, sports and down-filled textiles!)

– Reduce the detergent dosage for the next wash cycle.

ʑ

Loud noises, vibrations

and “wandering” during

the spin cycle.

– Appliance feet fixed?

Secure the appliance's feet. a Installation Instructions

– Transportation safety devices removed?

Remove transportation safety devices.

a Installation Instructions.

ʑ

Display panel/indicator

lights do not function

while the appliance is

running.

– Power failure?

– Fuse tripped? Switch on/replace the fuse.

– If the fault occurs repeatedly, call customer service.

ʑ

The programme takes

longer than usual.

– Not a fault – unbalanced load detection system adjusts

imbalance by repeatedly distributing the laundry.

– Not a fault – foam detection system active – a rinse cycle

is switched on.

13

What to do if …

ʑ

Detergent residue on the

laundry.

– Occasionally phosphate-free detergents contain water-insoluble

residue.

– Select 2 Rinse or brush the laundry after washing.

If a fault cannot be rectified (switching the machine on and off) or a repair is required:

– Set the programme selector to  Off and pull out the mains plug.

– Turn off the tap and call customer service. a Installation instructions

Emergency release e.g. if power failure occurs

The programme continues running when the power supply is restored. If the laundry is still to

be removed, the door can be opened as described below:

Risk of scalding.

The detergent solution and laundry may be hot. If required, leave to cool

down.

Do not reach into the drum in case it is still rotating.

Do not open the door if you can still see water through the glass.

1. Set the programme selector to  Off, pull out the mains plug.

2. Drain the detergent solution. a Page 11

3. Pull down the emergency release with a tool and release.

The door can then be opened.

Customer service

ʑ

If you cannot rectify the fault yourself (What to do if ..., a Page 12, 13), please contact our

customer service. We will always find a suitable solution to avoid unnecessary visits by

technicians.

ʑ

You can find the contact data for your nearest customer service here or in the customer

service list (depending on the model).

ʑ

Please give customer service the product number (E-no.) and the production number (FD)

of the appliance.

Product number Production number

These instructions can be found: on the

inside of the washing machine door */the

open service flap * and the rear of the

appliance.

* depending on the model

ʑ

Rely on the competence of the manufacturer. Contact us.

You can therefore be sure that the repair is carried out by trained service technicians who use

genuine spare parts.

en Washing machine

operating instructions

Washing machine

WAP20160SG

WAP20160ID

Betyg

Mer om denna bruksanvisning

Vi förstår att det är trevligt att ha en pappersbruksanvisning för din Bosch WAP20160SG Tvättmaskin. Du kan alltid ladda ner bruksanvisningen från vår hemsida och skriva ut den själv. Om du vill ha en originalbruksanvisning rekommenderar vi att du kontaktar Bosch. De kanske kan tillhandahålla en originalbruksanvisning. Letar du efter bruksanvisningen för din Bosch WAP20160SG Tvättmaskin på ett annat språk? Välj ditt föredragna språk på vår hemsida och sök efter modellnumret för att se om vi har det tillgängligt.

Specifikationer

Alla bruksanvisningar för Bosch Tvättmaskiner
Fler bruksanvisningar för Tvättmaskiner

Vanliga frågor om Bosch WAP20160SG Tvättmaskin

Vårt supportteam söker efter användbar produktinformation och svar på vanliga frågor. Om du hittar en felaktighet bland våra vanliga frågor uppskattar vi om du meddelar oss detta via vårt kontaktformulär.

Relaterade produkter

Bruksanvisning

Bosch WAU28R90GB Tvättmaskin

Bruksanvisning

Bosch WFVC5400UC Tvättmaskin

Bruksanvisning

Bosch WGG254ZTSN Tvättmaskin

Bruksanvisning

Bosch WAJ20170GC Tvättmaskin

Bruksanvisning

Bosch WGE03400SN Tvättmaskin

Bruksanvisning

Bosch WAN28081GB Tvättmaskin

Bruksanvisning

Bosch WAT28650 Tvättmaskin

Bruksanvisning

Bosch WAN2822ESN Tvättmaskin

Relaterade kategorier
