IMPORTANT - Read these instructions carefully

before use and keep them for future reference. Your

child’s safety may be affected if you do not follow

these instructions.

1 Insert wheel axle into the hole on the underside of

the Glider Board. The wheel is secure when you

hear it click. Repeat on other side.

2 Slide ratchet straps between the lower support

bar and the brake rods..

3 Push attachment brackets onto lower support bar

until they clip into place.

4 Press ratchet lock tab (a) and slide ratchet strap

through opening (b). NOTE: DO not trap brake

wire between ratchet strap and lower support bar.

5 Push ratchet strap through until snug. Repeat on

other side.

To adjust Glider Board Anle:

Note: Glider board must be parallel to the ground

or slightly angled toward the stroller before use.

Depending on your stroller model, you may need to

adjust the angle.

6 Push the safety cover away from the tabs.

7 To Raise: Press gray tabs on right and left side of

Glider Board and pull edge up.

To Lower: Press gray tabs on right and left side of

Glider Board and push front edge down.

8 Pull safety cover back over the tabs.

To adjust Glider Board Lenth:

9 Pull handle on the rear underside of Glider Board.

10 Pull out to extend.

11 Push in to shorten.

Storae (while usin the stroller):

12 Raise Glider Board and unhook storage straps

from underside.

13 Hook storage straps around rear crossbar of

stroller frame.

Note: When stored, make sure the rear of the

Glider Board is not interfering with the back of the

stroller seat. Adjust Glider Board length for storage

if necessary.

Storae (while foldin the stroller):

14 The Glider Board wheels must be removed before

you can fold the stroller. Follow steps 12 and 13

of the Glider Board Storage instructions (above),

then remove the wheels. Press wheel release

button and gently pull out wheel to remove.

To Remove Glider Board:

15 Press ratchet lock tab and pull ratchet strap out.

Unclip attachment brackets.

ASSEMBLY INSTRUCTIONS

 WARNING: Recommended for children from 2

years old up to a maximum weight of 45 lbs (20kg).

• WARNING: Never leave child unattended.

 WARNING: Always secure seat recline strap by

snapping the D-ring to the recline clamp before

using the Glider Board.

 WARNING: Always ensure the safety covers are

covering the adjustment tabs prior to use.

 WARNING: Always make sure storage straps

are fastened to the underside of the Glider Board

before use.

 WARNING: Always make sure the ratchet straps

are securely tightened before use.

 WARNING: Do not run or skate with this product

attached to a stroller/pushchair.

WARNING:

EN

A

B
